10kw 100kw 220V/240V /360V/380V Full System Electronically Controlled Wind Turbine wind driven turbine roof top ventilator fan
- Category: >>>
- Supplier: Daotian Hongye New Energy (shenzhen) Co. Ltd.
Share on (1601221313603):
Product Overview
Description
Product Description
Brand Name | AUSEUSA |
Model Number | DT-NE-10k-100k |
Rated power | 10kW/20kW/30kW/50kW/100kW |
Rated voltage | 220v/240v/360v/380v |
10kw-100kw Electronically Controlled Wind Turbine | ||||||||||
Model | DTF-NE-10k | DTF-NE-20k | DTF-NE-30k | DTF-NE-50k | DTF-NE-100k | |||||
Rated power | 10kW | 20kW | 30kW | 50kW | 100kW | |||||
Maximum power | 12kW | 23kW | 33kW | 55kW | 110kW | |||||
Rated voltage | 220V/240V | 220V/240V/380V | 360V/380V | 360V/380V | 360V/380V | |||||
Start-up wind speed | 2.5m/s | 2.5m/s | 2.5m/s | 2.5m/s | 2.5m/s | |||||
Rated wind speed | 10m/s | 10m/s | 10m/s | 10m/s | 10m/s | |||||
Survival wind speed | 45m/s | 45m/s | 45m/s | 45m/s | 45m/s | |||||
tower height (m) | 10m | 15m | 18m | 18m | 24m | |||||
Wheel diameter | 6.6m | 7.8m | 10m | 12.8m | 20m | |||||
Number of blades | 3 slices | |||||||||
Blades material | reinforced glass fiber | |||||||||
Generator type | Three phase permanent magnet ac synchronous generator | |||||||||
Magnetic materials | NdFeB | |||||||||
Generator shell material | Carbon Steel | |||||||||
Braking mode | Electronically controlled yaw protection | |||||||||
Speed regulation | Electronically controlled yaw | |||||||||
Working temperature | -40℃～80℃ | |||||||||
Lubrication way | Lubrication grease | |||||||||
Recommended Battery | 200ah*12V*20 | 200AH*12V*30 | 150ah*12v*60 | 200ah*12V*90 | 200ah*12v*150 | |||||
