High quality cheap price Competitive price 2kw enclosed Metal pipe fiber laser cutting machine

Share on (1601222736076):


Price:$4,000.00

Quantity:


Product Overview

Description





1










This is an practical laser pipe cutting machine developed by Sanhe in combination with market demand for end-users of bulk pipe processing. The model is extremely cost-effective, It is capable to cut metal tubes up to 6 meters and the shortest tailing waste is only 90mm, which is a great saving of cost. It is an ideal choice for pipe processing enterprises. From configuration selection to assembly process, from post-training to after-sales service, the machine truly creates a laser cutting machine that customers can afford!









Specification

Specification



























































Model


Fiber laser cutting pipe machine


Tube length


6000mm


Maximum diameter


10-245mm


Fiber power


1000w/1500w/2000w/3000w/4000w/6000w


Laser length


1064nm


Beam quality


<0.373mrad


Cutting accuracy


± 0.05mm


Repeated positioning accuracy


± 0.03mm


Maximum operation speed


40 meters/minute


The cutting speed


Depends on the material


Auxiliary gas


Auxiliary gas air, oxygen, nitrogen


Position Type


red dot


Working Voltage


380V/50Hz










FAQ




1 - What is fiber laser?
A fiber laser is a special type of solid state laser. Generally, fiber lasers are optically pumped. This is done by coupling the radiation of diode lasers or other fiber lasers into the cladding or the core itself in a direction parallel to the fiber core. In many cases, double clad fibers are used in order to achieve higher output power.

2.-What's material can fiber laser cut?
All kinds of metal, such as Stainless Steel,Carbon Steel, Mild Steel, Galvanized Steel, Aluminum, copper, etc.

3 -Do You Have Agent Or Distributor In Our Country?
There are so many end-users in your country, and just we are looking for agent in your country, do you have any interest?

4 -Could You Ship The Machine To Our Address?
Usually how to ship the machine, by sea, by air, by land or even by internation express are considered, we will give you the best choice according to your adress and model, even budget.

5 -What is Sanhe-LASER advantages?

-Excellent beam quality (light-concentrating beam from optical fiber)

-Maintenance free (the entire optical fiber setups without lenses, mirrors)

-multilingual, more than 13 foreign languages

-2 years warranty , fiber laser cutter
