Fully Automatic Rotogravure Color Registration Plastic Film Roll Printing Machine Roto Gravure Printing Machine
- Category: >>>
- Supplier: Zhejiang Kete Machinery Co. Ltd.
Share on (1601223584166):
Product Overview
Description
This High Speed Gravure Printing Machine is Suitable For Roll To Roll Printing Materials Such As BOPP, CPP, PET, PVC, PE, Nylon,Metalized Film, Paper, Aluminum Foil, etc. It Is Widely Used In High-Quality Packaging Material Printing Industries.
● Independent Rotary type Unwinder and Rewinder ● Unwind and Rewind Auto Splicing and Cutting
● Doctor Blade Pneumatic Type Design ● Doctor Blade Moving Controlled by Separate Motor
● Shaft-less Printing Cylinder Loading Design ● With 7 Motor Drive Tensional Control System
● With Water Chilling System ● Auto Ink Recycle System
● With Computer Auto Color Register System ● With Web Video Inspection System
● With Ink Transfer Roller ● Optional: Reverse Printing Turn Bar
● Optional: Horizontal Auto Color Register ● Optional: Water Base Ink
● Optional: Ink Viscosity Controller
Model | KTGP-MS300 |
Printing Colors | 4 - 12 colors |
Printing Material Width | 850mm / 1050mm / 1250mm |
Max. Mechanical Speed | 300m/min |
Max. Printing Speed | 250m/min (roller diameter ≥ 160mm) |
Unwind Diameter | Φ600mm / Φ800mm |
Rewind Diameter | Φ600mm / Φ800mm |
Printing Cylinder Diameter | Φ120mm~Φ300mm |
Color Register Precision (Vertical) | ±0.10mm (BOPP or PET) |
Heating Way | Electric Heating / Gas Heating / Oil Heating |
Total Power: | About 240kw (8colors) |
Machine Weight | About 32000kg (8colors) |
Machine Size (LWH) | 18600 × 3900 × 3100mm (8colors) |
Machine Power | 3 Phase 220 / 380 / 440v 50/60Hz |
