Welt Milling Machine XM503K 0.5m Road Cold Planer Asphalt Machine
With 103kw Rated Power
XM503K is a municipal maintenance type milling machine, mainly used for urban street and country road milling operations. It can perform small-scale maintenance on the road surface, milling road markings, milling along the manhole cover, and digging trenches, etc.; In addition, it can be used as an auxiliary equipment for large-scale milling machine to perform welt milling to meet all-round milling requirements.

Performance Characteristics
Walking system: It adopts three-wheel low-speed, full hydraulic drive, which can solve the problem of insufficient climbing
ability and slipping.
Suspension system: The rear wheel is an independent suspended support wheel.The right rear wheel can swing back inwards to facilitate welt milling.
Milling system: adopts hydraulic transmission method, milling is stable and powerful; imported cutter heads ensure the service life of cutters.
Milling depth control: through the up and down adjustment of the left and right rear legs, wedge milling is allowed; a depth
sensor is installed on the rear legs to display the milling depth electronically.
Steering system: full hydraulic steering, with the characteristics of light and flexible operation.
Sprinkler system:The fan-shaped water nozzle sprays water on the cutter head to cool the cutter and reduce the spread of dust during milling. The large-capacity water tank can make the machine work uninterrupted for longer. Electric water pump, high-pressure spraying, the sprinkler head is easy to disassemble and clean.
Lighting system: The machine is equipped with night work lights to facilitate night work.


Product Parameters


Item
Unit
XM503K
Milling width
mm
500
Maximum milling depth
mm
210
Tool nose distance
mm
15
Number of tools
60
Rotor diameter with tool
mm
750
engine model
SC4H-C140
Engine manufacturers
Shangchai
Rated speed
rpm
2200
Rated power
Kw
103
Displacement
L
4.3
Fuel consumption at rated power
l/h
26.2
Comprehensive fuel consumption
l/h
10.5
Emission Standards
China-Ⅲ
Fuel tank
L
180
Water tank
L
330
Working speed
m/min
0-30.7
Walking speed
Km/h
0-7.5
Theoretical climbing ability
%
60
Milling drum maximum ground clearance
mm
210
Front tire size
mm
559*178
Rear tire size
mm
559*254
