MT Medical VET Pets Dynamic Digital Radiograghy system with Laptop Panel for Pet Hospital
- Category: >>>
- Supplier: Hefei Mt Medical Co. Ltd.Hefei Ltd.
Share on (1601225405111):
Product Overview
Description
You Maybe Also Like
Product Description
32KW Stationary Veterinary X-ray Machine
High resolution and high sensitivity X- ray flat panel detector
1. High resolution wireless flat panel detector ensures excellent image quality and reliable clinical diagnosis.
2.Fast imaging time, high efficiency, direct image formation on a computer, free of film processing.
3. Light weight design, IP56 protection level.
Imported intelligent high voltage X-ray generator
1.Low input current design, 220V conventional voltage without supply transformation.
2. Originally Toshiba imported tube with lower radiation and higher safety and health factor.
Simple operation and clear image
1. Anew generation flat panel of iRay Venu1717X specially tailored for pet DR.
2. Open APR integration with kV, mA and mAs control and exposure conditions per body thickness.
3. Special veterinary radiography mode, easy to operate and safe to use.
4. Pet information and image management is completed with one key by simple operation.
5. DICOM 3.0 interface supports image flipping, panning, cropping, annotation processing, and work list output.
Optimized and humanized design
1.Multiple self-protection and fault alarm function, safe and reliable.
2.Automatically save parameters in case of sudden power failure
without loss of data.
3. Four-way floating table with electromagnetic brake to ensure accurate positioning.
4. Applicable to standard sockets without mains voltage conversion.
5. Rotary visor is equipped with LED lighting/timer and can also be operated by foot switch or foot brake.
6. Restraint straps are designed to allow the radiologist to leave the control area during filming.
Unique clinical experience
1. High quality X-ray single block ensures more details and less dose.
2. Medical fiberboard counter tops to prevent scratches.
Remote contactless service (optional)
Remote debugging and control, rapid maintenance, repair, and upgrade.
2.Fast imaging time, high efficiency, direct image formation on a computer, free of film processing.
3. Light weight design, IP56 protection level.
Imported intelligent high voltage X-ray generator
1.Low input current design, 220V conventional voltage without supply transformation.
2. Originally Toshiba imported tube with lower radiation and higher safety and health factor.
Simple operation and clear image
1. Anew generation flat panel of iRay Venu1717X specially tailored for pet DR.
2. Open APR integration with kV, mA and mAs control and exposure conditions per body thickness.
3. Special veterinary radiography mode, easy to operate and safe to use.
4. Pet information and image management is completed with one key by simple operation.
5. DICOM 3.0 interface supports image flipping, panning, cropping, annotation processing, and work list output.
Optimized and humanized design
1.Multiple self-protection and fault alarm function, safe and reliable.
2.Automatically save parameters in case of sudden power failure
without loss of data.
3. Four-way floating table with electromagnetic brake to ensure accurate positioning.
4. Applicable to standard sockets without mains voltage conversion.
5. Rotary visor is equipped with LED lighting/timer and can also be operated by foot switch or foot brake.
6. Restraint straps are designed to allow the radiologist to leave the control area during filming.
Unique clinical experience
1. High quality X-ray single block ensures more details and less dose.
2. Medical fiberboard counter tops to prevent scratches.
Remote contactless service (optional)
Remote debugging and control, rapid maintenance, repair, and upgrade.
Specification
Technial Specifications | ||
Pixel size | 140μm | |
Pixel matrix | 3072×3072 | |
A/D Conversion | 16 bit | |
Voltage | 220V | |
Power | 32kW | |
Maximum voltage | 150kV | |
Maximum current | 400mA | |
Focus size | 1.0mm/2.0mm | |
Heat capacity | 150kHU | |
Bed size | 1400mm×700mm | |
Monitor | 24 inch | |
High voltage cable | 75kVDC | |
Company Profile
MT MEDICAL focus on OR & ICU Room Solutions, our main products: operation table, operation lamp, ceiling pendant, hospital bed,medical trolley, patient monitor,x-ray film viewer, medical cabinets, Digital x-ray machine, and other hospital furniture and veterinary equipment. We have a professional marketing team and After-sales team.Every year we have new product research and development. our main markets are 10% North American, 10% South American, 15% Middle East, 15% Southeast Asia, 10% Europe, 10% the Commonwealth of the Independent States, 10% Oceanic and others 5%. if you want to get more information, pls contact us.
Exhibition
Packaging &Shipping
FAQ
Q: Are you manufacturer?
A: Yes, we have our own R&D team and sales team, We provide you one-stop service.Q: Do you have CE, ISO13485?
A: Yes, our products are approved by CE, ISO13485
Q: Is OEM &ODM available in your factory?
A: Yes, you just offer us necessary documents and then we will produce the products as your requirements.
Q: What is your Payment term?
A: 1.L/C at sight
2.T/T: 30% deposit by T/T, 70% balance by T/T before shipment
3.Trade term: EXW, FOB Shanghai or CIF&CFR
Q: What is your Packing details?
A: 1.Wooden case or carton package, standard export packages
2.All of the productions are inspected carefully by QC before delivery
Q: What is your Min.order?
A: There's no minimum quantity.
A: Yes, we have our own R&D team and sales team, We provide you one-stop service.Q: Do you have CE, ISO13485?
A: Yes, our products are approved by CE, ISO13485
Q: Is OEM &ODM available in your factory?
A: Yes, you just offer us necessary documents and then we will produce the products as your requirements.
Q: What is your Payment term?
A: 1.L/C at sight
2.T/T: 30% deposit by T/T, 70% balance by T/T before shipment
3.Trade term: EXW, FOB Shanghai or CIF&CFR
Q: What is your Packing details?
A: 1.Wooden case or carton package, standard export packages
2.All of the productions are inspected carefully by QC before delivery
Q: What is your Min.order?
A: There's no minimum quantity.
