Product Overview
Description
Introduction
The trainer, properly designed for educational aims, allows the student to study the operation of commercial refrigerator with two evaporators, one hermetic compressor and one air condenser
R407a environmental refrigerant, refrigeration effect 12000BTH/h
Single phase 220V to 240V, 50Hz
2 units condenser and 2 units wall hung evaporator
Fan coil unit mounted onto board
Condenser unit mounted onto floor or f the framework
The unit is suplied with all material required for installation
The frame is fitted with heavy duty caster wheels with break
Dust filter, 2 check valves mounted after dryer filters
Supply all necessary spare parts, intallation tools
Floor trap tray
Aluminum( which is better than steel), corrosion resistant outer casting stand
R407a environmental refrigerant, refrigeration effect 12000BTH/h
Single phase 220V to 240V, 50Hz
2 units condenser and 2 units wall hung evaporator
Fan coil unit mounted onto board
Condenser unit mounted onto floor or f the framework
The unit is suplied with all material required for installation
The frame is fitted with heavy duty caster wheels with break
Dust filter, 2 check valves mounted after dryer filters
Supply all necessary spare parts, intallation tools
Floor trap tray
Aluminum( which is better than steel), corrosion resistant outer casting stand
Training Program
Plant starting and verification of the safely devices intervention
Study of the operation of a thermostatic expansion valve
On-off control
Analysis of the system behavior at variation of:
- Number of evaporators
- Condenser evaporations air flow
- Thermostatic valves superheat
Drawing the cycle in the pressure-enthalpy diagram of the refrigerant gas
Data collection and calculation of:
- Thermal balances at the evaporators, condenser, compressor
- Refrigerant mass flow
- Compressor volumetric efficiency
- Thermostatic valve superheat
Study of the operation of a thermostatic expansion valve
On-off control
Analysis of the system behavior at variation of:
- Number of evaporators
- Condenser evaporations air flow
- Thermostatic valves superheat
Drawing the cycle in the pressure-enthalpy diagram of the refrigerant gas
Data collection and calculation of:
- Thermal balances at the evaporators, condenser, compressor
- Refrigerant mass flow
- Compressor volumetric efficiency
- Thermostatic valve superheat
Supplied
English General Refrigeration Manual
English Experimental Handbook
English Experimental Handbook
