Aluminum Steel Arc Welding Machine Mig Welding Machine Carbon Dioxide Gas Shielded Welding Machine
- Category: >>>
- Supplier: Foshan Tomde Welding Equipment Co. Ltd
Share on (1601231314457):
Product Overview
Description
Rated input voltage/frequency | Three-phase 380v±10% 50/60hz |
Rated input capacity (KVA) | 16 |
Rated input current (A) | 23 |
Duration of rated load (%) | 60 |
Duration of rated load (%) | 33 |
Output current Range (A) | 40-380 |
Wire feed speed（m/min) | ≥28 |
Number of voltage regulation files | 30 |
Dimensions W*D*H(MM) | 730*390*780 |
Application | Machinery, steel structure, furniture manufacturing, hardware accessories, electric motorcycle carriage and accessories, bicycle industry |
FEATURES | Integrated, built-in wire feeder, dust and moisture, reduce the point of failure. High efficiency, wire feed speed up to 28m/min, welding efficiency is several times higher than manual arc welding. The main circuit rectifier bridge adopts multi-tube rectifier bridge group, which has strong overload capacity and stable and reliable performance. The machine has low failure rate and long service life. The welding voltage can be adjusted in 30 grades, with wide adjustment range and convenient adjustment. Small welding splash, small deformation, beautiful weld forming. With continuous welding, spot welding, gap welding and other functions. It is mainly suitable for welding of thin, medium and low carbon materials above 0.4MM. Suitable wire diameter (mm) 0.8/1.0/1.2, with 1.0/1.2 welding effect is better. |
Q: How about your after-sales service?
A: Our main engine warranty is one year (non-human fault)
Q: What are your terms of payment?
A: Our terms of payment are 30% down payment with the balance to be paid before delivery.
Q: If we make our own Logo, what is the minimum quantity?
A: The minimum order quantity is 10 units per model.
Q: Do you have any certificates?
A: We have CQC certification.
A: Our main engine warranty is one year (non-human fault)
Q: What are your terms of payment?
A: Our terms of payment are 30% down payment with the balance to be paid before delivery.
Q: If we make our own Logo, what is the minimum quantity?
A: The minimum order quantity is 10 units per model.
Q: Do you have any certificates?
A: We have CQC certification.
