China Top Brand 16ton New Lifting Machinery Mobile Truck Crane STC160 for Hot Sale
- Category: >>>
- Supplier: Evangel Industrial (Shanghai) Co. Ltd.Evangel Ltd.
Share on (1601231420013):
Product Overview
Description
Contact Way
Gardenia Zhang
We can provide you with new or used construction machinery, and can also make certain modifications based on your requirements. If you need to inquire about the price, please contact me!
Sales Manager
WhatsApp/WeChat/Mobile: +86- 180 7539 2133
WhatsApp/WeChat/Mobile: +86- 180 7539 2133
Email: gardenia@evangelchina.com
Company website: www.evangelchina.com
Company website: www.evangelchina.com
We can provide you with new or used construction machinery, and can also make certain modifications based on your requirements. If you need to inquire about the price, please contact me!
Products Description
16ton Truck Crane STC160 with Cheap Price
Compact Design
· The three-axle cranes are capable of accessing various urban or small jobsites, featuring high flexibility and fast transferring.
Double Pump Intelligent Flow Distribution System
· The electro-hydraulic control system realizes effective flow distribution, featuring quick response to combined motions and small impact shock, energy saving, and environmentally friendly. Precise control: Excellent inching performance, min. The stable speed of a single rope is 1.2m/min and min. The sound speed of slewing is 0.1°/s, realizing precise lifting of mm level. Integrated slewing buffer control: boost buffer, sequential brake, and free swing technology—smooth start and stop.
High-performance Chassis
· Innovative structural frame verified by 200,000 cycling fatigue tests to ensure high reliability.
Smart Control System
· CAN BUS system: Controllers, displays, meters, I/O modules, sensors, etc., are integrated into CAN Bus networking and fast-responsive.
· Fault diagnosis system: Operating device with intelligent controller, body with BCM module, accurately locating the fault point, making the maintenance convenient.
· The load moment indicator system protects against overloading, over-release, and over-winding.
Precision & Economy
· Valves and other hydraulic components realize better inching motion performance. Load-sensing and constant-power techniques optimize fuel efficiency.
· The three-axle cranes are capable of accessing various urban or small jobsites, featuring high flexibility and fast transferring.
Double Pump Intelligent Flow Distribution System
· The electro-hydraulic control system realizes effective flow distribution, featuring quick response to combined motions and small impact shock, energy saving, and environmentally friendly. Precise control: Excellent inching performance, min. The stable speed of a single rope is 1.2m/min and min. The sound speed of slewing is 0.1°/s, realizing precise lifting of mm level. Integrated slewing buffer control: boost buffer, sequential brake, and free swing technology—smooth start and stop.
High-performance Chassis
· Innovative structural frame verified by 200,000 cycling fatigue tests to ensure high reliability.
Smart Control System
· CAN BUS system: Controllers, displays, meters, I/O modules, sensors, etc., are integrated into CAN Bus networking and fast-responsive.
· Fault diagnosis system: Operating device with intelligent controller, body with BCM module, accurately locating the fault point, making the maintenance convenient.
· The load moment indicator system protects against overloading, over-release, and over-winding.
Precision & Economy
· Valves and other hydraulic components realize better inching motion performance. Load-sensing and constant-power techniques optimize fuel efficiency.
Specification
Dimension | Unit | STC160 |
Overall length | mm | 11000 |
Overall width | mm | 2500 |
Overall height | mm | 3640 |
Engine rated power | kW/(r/min) | 192/2300 |
Engine rated torque | N.m/(r/min) | 960/1400 |
Travel | ||
Max. travel speed | km/h | 80 |
Min. turning diameter | m | 10.5 |
Max. grade ability | % | 40 |
Fuel consumption for 100km | L | 28 |
Main performance | ||
Max. rated total lifting capacity | t | 16 |
Base boom | m | 10.5 |
Fully extended boom | m | 32 |
Fully extended boom+ jib | m | 40 |
Boom luffing time | s | 50 |
Boom full extension time | s | 65 |
Max. swing speed | r/min | 2.1 |
Max. speed of main winch (single rope) (no load) | m/min | 105 |
Max. speed of aux. winch (single rope) (no load) | m/min | 105 |
