Enneng permanent magnet magnetic generator 10kw 15 kw 20kw 220v 100 rpm 40rpm
- Category: >>>
- Supplier: Qingdao Enneng Machinery Co. Ltd.
Share on (1601233258752):
Product Overview
Description
Product Drawing
Product Description
Rated power | 12kW-3000kw |
Rated speed | 300rpm |
Rated voltage | 220VAC |
Frequency | 60Hz |
Numbers of Poles | 24 |
Insulation Class: | H |
Protection Class | IP54 IP55 |
Efficiency | 93% |
Cooling Method | Natural cooled |
Ambient temperature | -25~45℃ |
Recommended altitude | ≤ 1000m |
Bearings | SKF Ball Bearings |
Winding material | 100% Copper |
Winding temperature level | 180℃ |
Stator Impregnation type | Vacuum Pressure Impregnation (VPI) |
Normal working temperature | 90℃ |
Max working temperature | 130℃ |
Installation | Horizontal |
Details Images
Working Principle
The permanent magnet generator uses the principle of electromagnetic induction in that the wire cuts the magnetic field line to induce an electric potential and converts the mechanical energy of the prime mover into electrical energy output. It consists of two parts, the stator, and the rotor. The stator is the armature that generates the electricity and the rotor is the magnetic pole. The stator is composed of an armature iron core, uniformly discharged three-phase winding, machine base, and end cover.
The rotor is usually a hidden pole type, which is composed of excitation winding, iron core and shaft, guard ring, center ring, and so on.
The excitation winding of the rotor is fed with DC current to generate a magnetic field close to the sinusoidal distribution (called the rotor magnetic field), and its effective excitation flux intersects with the stationary armature winding. When the rotor rotates, the rotor's magnetic field rotates together with it. Every time a revolution is made, the magnetic lines of force cut each phase winding of the stator in sequence, and a three-phase AC potential is induced in the three-phase stator winding.
When the pm generator is running with a symmetrical load, the three-phase armature current synthesizes to generate a rotating magnetic field with synchronous speed. The stator and rotor fields interact to generate braking torque. The mechanical torque input from the turbine overcomes the braking torque and works.
The rotor is usually a hidden pole type, which is composed of excitation winding, iron core and shaft, guard ring, center ring, and so on.
The excitation winding of the rotor is fed with DC current to generate a magnetic field close to the sinusoidal distribution (called the rotor magnetic field), and its effective excitation flux intersects with the stationary armature winding. When the rotor rotates, the rotor's magnetic field rotates together with it. Every time a revolution is made, the magnetic lines of force cut each phase winding of the stator in sequence, and a three-phase AC potential is induced in the three-phase stator winding.
When the pm generator is running with a symmetrical load, the three-phase armature current synthesizes to generate a rotating magnetic field with synchronous speed. The stator and rotor fields interact to generate braking torque. The mechanical torque input from the turbine overcomes the braking torque and works.
Main Features
① The generator has many poles,which improve the frequency and efficiency,saving the cost of rectifiers and inverters.
② Finite Element Analysis is used when designing the generator,compact structure. Low startup torque,solves the problem of small wind startup,improving the wind energy utilization.0
③ Leave out the gear increaser,improve the reliability and efficiency of the generator,lower the amount of maintenance.
④ H class insulation,vacuum pressure impregnation.
⑤ Have many structures such as vertical axis,horizontal axis,internal rotor,external rotor,plate type.
⑥ Strong rotors ,the generator could achieve high speed.
⑦ Small size ,light weight,high energy density,suitable for special situations.
⑧ Run efficiency throughout the whole speed range,high efficient.
⑨ Use imported high-speed oil-contained bearings,maintance free,high reliablity.
② Finite Element Analysis is used when designing the generator,compact structure. Low startup torque,solves the problem of small wind startup,improving the wind energy utilization.0
③ Leave out the gear increaser,improve the reliability and efficiency of the generator,lower the amount of maintenance.
④ H class insulation,vacuum pressure impregnation.
⑤ Have many structures such as vertical axis,horizontal axis,internal rotor,external rotor,plate type.
⑥ Strong rotors ,the generator could achieve high speed.
⑦ Small size ,light weight,high energy density,suitable for special situations.
⑧ Run efficiency throughout the whole speed range,high efficient.
⑨ Use imported high-speed oil-contained bearings,maintance free,high reliablity.
⑩ The parameters like voltage,speed,power can be customized.The shape can be changed.Spline shaft,biaxial extension,flange can be used.
Factory Show
FAQ
1. Q: How does your permanent magnet generator work?
A: Our generator needs to be driven by other energy, like wind power, water power, belt, etc, then it can generate electric power.
A: Our generator needs to be driven by other energy, like wind power, water power, belt, etc, then it can generate electric power.
2. Q: What is the power of your generator?
A: We can manufacture from 12kw to 5000kw.
A: We can manufacture from 12kw to 5000kw.
3. Q: Can you manufacture customized product?
A: Yes, we can.Please tell your detailed request (power, rpm, voltage, size, color) to our sales, we will make the generator according to your request.
4. Q: Can your company provide OEM service?
A: Yes, we can.
