Product Overview
Description
Mig Welding Machine Price List CO2 Welding Equipment MIG 350 Welding Machine
■ Preset the speed of wire feeding or welding current, unify adjustment, intuitionistic and simple
■ Self一locking function to reduce the labor intensity of welders in large specification long seam welding
■ With CO2/ MAG / manual arc welding / carbon arc gouging (MIG-SOON / 630N) and other functions, the switch control is selected,
and the function switching is intuitive and simple.
■ Waveform control technology, small splash, beautiful forming
■ Function to remove welding ball at arc end time, and arc striking process is smooth and quick
■ Easy to set welding parameters of Pre-flow time, time delay of gas stop, etc.
■ Welding cable can extend to 100 meters, stable welding
■ Main power part & control board "3 defenses" treatment protect from moisture, salt fog and dust
■ Protect functions such as overheating, overcurrent, overvoltage and output short circuit etc.
■ The external interface is abundant, and it can be used to match special machine.
■ Intelligent control of fan, power saving
■ with manual arc welding function
■ Self一locking function to reduce the labor intensity of welders in large specification long seam welding
■ With CO2/ MAG / manual arc welding / carbon arc gouging (MIG-SOON / 630N) and other functions, the switch control is selected,
and the function switching is intuitive and simple.
■ Waveform control technology, small splash, beautiful forming
■ Function to remove welding ball at arc end time, and arc striking process is smooth and quick
■ Easy to set welding parameters of Pre-flow time, time delay of gas stop, etc.
■ Welding cable can extend to 100 meters, stable welding
■ Main power part & control board "3 defenses" treatment protect from moisture, salt fog and dust
■ Protect functions such as overheating, overcurrent, overvoltage and output short circuit etc.
■ The external interface is abundant, and it can be used to match special machine.
■ Intelligent control of fan, power saving
■ with manual arc welding function
Model | MIG-350N |
Rated input voltage/frequency | 3～380V±10% 50/60HZ |
Rated input power(KVA) | 14 |
Rated input current(A) | 21 |
Rated duty cycle(%) | 60 |
Open-load-voltage(V) | 70 |
Range of output current(A) | 60-350 |
Range of output voltage(V) | 12-40 |
Power factor | ≥87 |
Wire diameter(mm) | 1.0-1.6 |
Gas flow(L/min) | 15-20 |
Torch cooling method | Air cool |
Enclosure protection degree | IP21 |
Insulation grade | F |
Power source N.W(kg) | 42 |
Power supply dimensions W×D×H(mm) | 340×660×650 |
