Product Overview

Description







Overview













Product Description


Multi speed sc200 construction building hoist lift single cage 2tMulti speed sc200 construction building hoist lift single cage 2t


Hot sale construction passenger elevator construction lift and hoists construction electric winch hoist















































































































































Technical parameters

 Unit


 SC200/200 Frequency Construction hoists
 Height m

 300


 Rated load kg2000/2000
 Maximum capacity  009/009
 Boom lift wweight kg≤200
 Lifting speed m/min 0-40 0-45 0-55 0-66
 Electormotor  Model  YZEJ132M(L)-4

 Power


 kw 15×2/15×2 11×3/11×3 15×3/15×3 18.5×3/18.5×3
 Speed-limiter   Model   SAJ40-1.2A   SAJ40-1.4
 Rated tripping speed m/s 1.2/1.4
 Standard motion speed  m/s 1.1/1.35
 Rated automaticload KN

 40


 Type  gradual
 Reducer Model  SWC1  TU68T  TU66T
 Center distancemm 125
 Speed radio  1:12  1:10
 Bracking distancem 0.3-1.2
 Mast section dimensionmm 650×650×1508
 Crane cage inner net dimensionm 3.0×1.3×2.2  3.2×1.5×2.2
 Guardrail dimensionm 5.53×3.42×1.82 5.93×3.62×1.82
 Hoistway dimensionsm
 Free end height of the guide rail framem ≤9
 Gounterweight weightkg
 Direct attached frame Installing intervalm/set 006-9
 Distance between two embedded partsmm ≈1488
 Installation dimensions from center of rail frame to building wallmm 2800-3200
 Safe and protection system Upper and below limited switches,upper and below limit utmost switches,gate limited switch,falling avoiding safe device,cushion device,safe lock of gate,counterweight rope breaking or loose protecting device,safe hook,The safety device against overload,Anti-punching standard section  etc.

Multi speed sc200 construction building hoist lift single cage 2tMulti speed sc200 construction building hoist lift single cage 2tMulti speed sc200 construction building hoist lift single cage 2t
