Price:$5,900.00 - $13,000.00

Quantity:


Product Overview

Description



Pneumatic 100-500m Water Well Drilling Machine With Air Compressor


Specification




Model
YGF-180
YGF-200
YGF-260
YGF-300
Weight (Ton)
4.5
5
6.5
7.2
Drilling Diameter (mm)
140~254
140~254
140~305
140~325
Drilling Depth (m)
180
200
260
300
Walking Speed (Km/h)
2.5
2.5
2.5
2.5
Climbing Angles (°)
30
30
30
30
Equipped capacitor (Kw)
55
65
70
85
Using Air Pressure (Mpa)
1.7~2.5
1.7~3.0
1.7~3.0
1.7~3.0
Air Consumption (m³/Min)
17~31
17~31
17~31
17~36
Drilling Pipe Length (M)
1.5/2/3
1.5/2/3
1.5/2/3
1.5/2/3
Rig Lifting Force (T)
12
13
20
24
Swing torque (N.m)
3200-4600
3400-4700
4000-5300
5700-7500
Swing speed (rpm)
45-70
45-70
45-70
45-70
Dimension (mm)
3950*1630
*2250
3950*1750
*2250
4000*1850
*2300
4100*2000
*2500
Please contact the sales staff for more parameters and model information!


Product Description


YG made deep water well drilling rig used newest model & advanced hydro technology, with high torque hydraulic motor rotation and large cylinder hydraulic cylinder advancement.
Our water well drilling machine are mainly used for well drilling in resource exploration hydrology wells, civil usage water well, agriculture irrigation project, and can also be used for coal-mine gas exploitation, shallow layer of shale gas.Made from high quality materials, with fashion and compact design, that keeps our drilling rigs more efficiency and with low failure rate, more economic and durable, rigs have received the real market validation as the majority of our customer’s positive feedback.

Feature
1.Hydraulic oil pump; parallel transmission design (patent) oil pump single body, power supply adequate distribution reasonable,
hydraulic system unique design, simple maintenance cost small.
2.Used with air compressor, can drill 180M, 200M, 300M, 400M, 500M ,600M, 800M, etc.
3.Usually drilling diameter is 6‘’, 8'', 10'', 12'', 14'',etc. According to your needs, we can configure the suitable drill pipe, drill bit and the right model.
4. Power head device; gearbox casting, double motor power supply, torque, durability, maintenance costs are small.
5. Drilling rig chassis; Professional excavator chassis, durable, heavy load bearing, wide chain board, little damage to hard road surface.




Details Images


High quality raw materials
Professional excavator chassis, durable, heavy load bearing, wide chain board, little damage to hard road surface.

More efficienc, low failure rate, economic and durable

Used with air compressor, depth up to 800 meters.

Power head device; gearbox casting, double motor power supply, torque, durability, low maintenance costs.


Air Compressor
Optional equipment
Mud Pump
Optional equipment
Drilling Rod
Determined according to the size of the hole


Hammer
Determined according to the size of the hole
DTH Drilling Bit
Determined according to the size of the hole
Open Hole Bit
Determined according to the size of the hole
