Three axis high speed drilling machine TX T600 three axis CNC machining center
- Category: >>>
- Supplier: Xiamen Mibay Technology Co. Ltd.
Share on (1601238491951):
Product Overview
Description
High speed drilling machine TX-T600
Product description:
•The main structure is made of high-grade Mihanna cast iron, which is solid in structure, light and flexible, quick in response and small in floor space;d-
•Direct connection spindle, high speed, low vibration, low noise, low temperature rise; Capable of long-term high-speed machining operations;
•Precision linear slide rail is adopted for three axes; High rigidity, low noise, fast stroke and excellent stability;
•The three-axis adopts a large-diameter ball screw, which can meet the requirements of different feed speeds and feed resolutions
•The three-axis motor and ball screw are directly driven, with high positioning accuracy and no back clearance issues;
•The institutional design fully conforms to ergonomic principles, and the mechanicall sheet metal cover is designed based on the convenience of machine use
•Precision linear slide rail is adopted for three axes; High rigidity, low noise, fast stroke and excellent stability;
•The three-axis adopts a large-diameter ball screw, which can meet the requirements of different feed speeds and feed resolutions
•The three-axis motor and ball screw are directly driven, with high positioning accuracy and no back clearance issues;
•The institutional design fully conforms to ergonomic principles, and the mechanicall sheet metal cover is designed based on the convenience of machine use
Technical parameters and configuration list
1. Mechanical parameter table
Items Unit | T-600 T-1000 T-2000 | |||||||
Stroke | ||||||||
X-axis stroke | mm | 600 | 1000 | 2000 | ||||
Y-axis stroke | mm | 450 | 500 | 500 | ||||
Z-axis stroke | mm | 330 | 330 | 330 | ||||
Spindlenose endto workbench | mm | 150-480 | 150-480 | 150-480 | ||||
Spindle | ||||||||
Spindle rotation connection | r.p.m | 15000/20000 | 15000/20000 | 20000/24000 | ||||
Spindletaper | BT30 | BT30 | BT30 | |||||
Spinde motor (continuous/30 split stop | kw | 5.5 | 5.5 | 5.5 | ||||
X.Y.Z three-axis motor | kw | 1.5/1.5/3.0 | 2.0/2.0/3.0 | 3.0/3.0/3.0 | ||||
Workbench | ||||||||
Workbench area | mm | 700x420 | 1100x500 | 2100x500 | ||||
T-shaped groove (width number of groovesXspacing) | mm | 3-14×125 | 3-18×100 | 3-18x100 | ||||
Maximum load of workbench | kg | 300 | 400 | 600 | ||||
Feed | ||||||||
Three-axisrapid displacement | mm/min | 48000 | 48000 | 36000 | ||||
Chip feed rate | mm/min | 1-10000 | 1-10000 | 1-10000 | ||||
Acouracy | ||||||||
Positioning accuracy | mm | ±0.005/300 | ±0.005/300 | ±0.005/300 | ||||
Repeatability | mm | ±0.003/300 | ±0.003/300 | ±0.005/300 | ||||
Others | ||||||||
System configuration | FANUC/MITSUBISH | |||||||
Number of cutting tools | T | 21 | 21 | 21 | ||||
Maximum avalabletooldiameter | mm | 60/80 | 60/80 | 60/80 | ||||
Tool exchange method | Clamp arm type | Clamp arm type | Clamp arm type | |||||
Machine dimensions | mm | 1950×2455×2400 | 2700×2300×2500 | 3200*2400*2800 | ||||
Machine weight | kg | 3300 | 4500 | 7500 | ||||
*The specifications may change with the improvement ofquality,and we apologize for any inconveniencecaused. | ||||||||
Exhibition
Contact us
FAQ
1. How should i pay for my order ?
what is the procession of this purchase ? We accept TT by bank or other methods. You can do 30%prepayment at first, then we will start to make production.When the machine is ready , we will take pictures to you, and then youcan do the balance. I will send the machine to you after we got your payment.
2. How about your service after sales ?
can your Engineer speak fluent english ? We offer the service from you got the machine, including how to install the machine,how to use machine, how to let machine work.,and so on. Usually ,we will teach you how to do by email or by skype our engineer who has many years of experience for cnc machine service . he can speak fulently in english .so he can slove the problem in short time.
3. Are you a factory or trading company?
We are the manufacturer . As only the machine made by ourself ,quality can be trusted, and most important thing is we can do better service after sales. we know how to fix the problem in each parts easliy. so welcome to visit our factory.
4. How long is the delivery time?
For standard machines, it would be 5-7 days; For non-standard machines and customized machines according to client s specific requirements, it would be 10 to 20 days. 5. How about the documents after shipment? Aftershipment,will send all original documents to you by DHL, including Packing List, Commercial Invoice, B/L, and other certificates as required by client.
