Flygoo Ozone Meter Detector for Gas Signal Output 4-20mA and RS485 Digital Signals


Product Description


FGZH-180 ozone analyzer is designed and manufactured based on Lambert Beer's law and the verification and calibration methods for measuring ozone gas using ultraviolet spectrophotometry. By measuring the changes in light signal intensity before and after the absorption of ultraviolet light by ozone, the current ozone concentration value can be calculated.

The equipment uses an advanced dual path ultraviolet light source system, which is equipped with an intelligent lamp management system.It has pressure and temperature compensation and display, and can set automatic zero calibration time and manual zero calibration mode.






24/7 Working
Accuracy
Low Price


Signal Output
Data Storage
Compacted


Specification


Model
FGZH-180
Working principle
UV LED absorption method
Range
0-200g/Nm3; 0-100g/Nm3; 0-50g/Nm3
Display resolution
0.01g/Nm3
Gas flow rate
0.3L-0.8L/min
Input pressure
<0.1MPa
Concentration error
maximum 0.5% FS
Linear error
maximum 0.5% FS
Zero drift
<± 0.4%. FS
Sampling port diameter
Φ 6 (6mm*4mm)
Communication method
RS-485
Output mode
4-20mA
Power supply
24V DC
Size
150 x 75 x210mm
Hole size
152 x 76mm
Weight
3KG
Standard configuration
Anti-corrosive flow meter, ozone exhaust
destructor, intake filter


Feature


1.Embedded desktop ozone analyzer
2.With automatic zero calibration function
3.Dual light path ultraviolet absorption principle
4.Signal output 4-20mA and RS485 digital signals
5.Long life ultraviolet LED light
6.Automatic zero calibration function
7.Touch screen operation interface
8.Longer service life and faster response speed
