High Quality Veterinary Biological Trinocular Binocular Digital Usb Camera Binoculaire Microscope For Laboratory
- Category: >>>
- Supplier: Qingdao Ansha Pharmaceutical Co. Ltd.
Share on (1601241193374):
Product Overview
Description
Product Description
Product Features:
1. The light source uses a high-brightness, continuously adjustable LED lamp, which has a long lifespan and is easy to maintain, ensuring excellent quality.
2. The microscope is equipped with an adjustable Abbe condenser and Köhler illumination, offering a wide range of condenser adjustments and good image contrast.
3. It allows free switching between two light paths: one for microscopic observation and one for connecting to imaging devices.
4. The microscope features a dual-layer mechanical stage with a scale ruler and coaxial X-Y adjustment knobs, providing ease of operation.
1. The light source uses a high-brightness, continuously adjustable LED lamp, which has a long lifespan and is easy to maintain, ensuring excellent quality.
2. The microscope is equipped with an adjustable Abbe condenser and Köhler illumination, offering a wide range of condenser adjustments and good image contrast.
3. It allows free switching between two light paths: one for microscopic observation and one for connecting to imaging devices.
4. The microscope features a dual-layer mechanical stage with a scale ruler and coaxial X-Y adjustment knobs, providing ease of operation.
Typical Applications:
1. Teaching and experimentation
2. Routine laboratory tests in hospitals
3. Agriculture, forestry, fishery, and aquaculture
4. Biological and pathological sectioning, bacterial observation
5. Various types of fibers
6. Powder particles
7. Micro-objects in liquids
8. Carbon black in pipes
9. Chemical and cosmetic products
1. Teaching and experimentation
2. Routine laboratory tests in hospitals
3. Agriculture, forestry, fishery, and aquaculture
4. Biological and pathological sectioning, bacterial observation
5. Various types of fibers
6. Powder particles
7. Micro-objects in liquids
8. Carbon black in pipes
9. Chemical and cosmetic products
Packing List | ||||
Microscope Main Unit | 1 | |||
Plan Eyepiece 10X | 1 Pair | |||
Achromatic Objective Lenses | 4X, 10X, 40X, 100X | 1 each | ||
Fuse | 1 | |||
Immersion Oil | 1 Bottle | |||
Dust Cover | 1 | |||
Power Cord | 1 | |||
Random Accessories | Packing list, manual, certificate, warranty card | 1 each | ||
Optional Accessories
Microscope Optional Accessories | ||
Eyepiece | 10X micrometer eyepiece, 16X eyepiece | |
Plan Achromatic Objective Lens | 4X/0.10, 10X/0.25, 20X/0.40, 40X/0.65, 100X/1.25 (oil) | |
Objective Micrometer | 0.01mm | |
Imaging System Options | ||
Electronic Eyepiece | 350K, 1MP, 2MP, 3MP, 5MP (capable of single-shot, timed, and continuous image capture, with scale display, measurement functions, and various output options including multimedia, printing, and EMAIL) | |
CMOS Digital Camera | 3.2MP, 5MP, 6.3MP, 8.3MP, 12MP, 20MP (capable of single-shot, timed image capture, video recording, scale display, measurement, image stitching, and more, with various output options) | |
CCD Digital Camera | 6MP, 12MP (same functions as CMOS camera) | |
High-Definition Analog Camera | 580 lines (Japanese JVC, Panasonic, and domestic brands, with single-shot, timed image capture, video recording, and more) | |
VGA Digital Camera | 1MP, 2MP (direct display connection, single-shot image capture, crosshair display, scale addition, measurement, and more) | |
HDMI Video Camera | 1MP, 2MP (same as VGA camera) | |
DSLR Camera | Canon, Nikon, Leica, with megapixel sensors and features for photography and video recording | |
Analysis Software Options | ||
Basic Measurement Software UV | Single-shot, timed, and continuous capture, scale and magnification display, various measurements (length, angle, radius, perimeter, area), and multiple output options including multimedia, printing, and EMAIL | |
Biological Software UV-P | Similar to UV, with additional functions for analyzing biological cells, bacteria, glands, etc. | |
Particle Size Software UV-G | Includes all basic measurement functions, calculates area proportion of different colors, measures and analyzes particles automatically, outputs distribution charts and statistics for various parameters (D10, D50, D90, etc.) | |
Carbon Black Software UV-T | Specifically designed for testing pigment or carbon black dispersion in polyethylene pipes, following national standard GB/T 18251-2000, with automatic grading and report generation. | |
Fiber Analysis Software | CU-1, CU-2, CU-3 series, PS-WT2 fiber software, UV-TXW carbon fiber software, measures diameter, content, cross-sectional area of various fibers, with automated analysis, statistics, and output | |
One-Drop Blood Software | Captures blood images, detects various blood types and diseases, compares with standard images to assess health status, with comprehensive case file management and multiple output options | |
Specification
item | value |
Warranty | 1 Year |
After-sale Service | Online technical support |
Place of Origin | China |
Brand Name | N/A |
Model Number | V1500 |
Power Source | Manual |
Material | Metal, Plastic, Steel |
Shelf Life | 1years |
Quality Certification | CE |
Instrument classification | Class I |
Wide-field eyepiece | WF10X/ 20mm |
Achromatic objective lens | 4X/0.10, 10X/0.25, 40X/0.65, 100X/1.25 |
Total magnification | 40X-1000X |
Observation head | Trinocular, hinged, 30° inclined, 360° rotatable |
Nosepiece | Quadruple (internal ball bearing positioning) |
Interpupillary distance | 55-75mm |
Illumination | 5W high-brightness LED with adjustable brightness |
Instrument weight | Net weight 7.0 kg, gross weight 9.5 kg |
