Chinese Top Brand LTD733H 33Ton Heavy Hydraulic Double Drive Single Drum Hydraulic Vibratory Road Roller High Quality for Sale
- Category: >>>
- Supplier: Cruking Engineering Equipment (Xiamen) Co. Ltd.Cruking Ltd.
Share on (1601244626619):
Product Overview
Description
Chinese Top Brand LTD733H 33Ton Heavy Hydraulic Double Drive Single Drum Hydraulic Vibratory Road Roller High Quality for Sale
Contact Way
Product Overview
• Front wheel hydraulic vibralion, hydraulic steering, rear wheel drive, strong climbing abilily.
• Hydrostatic rear wheel drive, stepless speed change, One joystick operation, advanced technology, light and comfortable
operation, safe and reliahle.
• Special vibrating wheel technology, large centrifugal force, high compactness and high working efficiency.
• Articulated frame, light steering, small turning radius, flexible maneuver.
• The rear hood can be turned freely at large angle, Engine inverted, the humanized layout, and the maintenance is within reach.
• Unique appearance modeling, compact structure, low center of gravity, smooth driving, good front and rear view.
• Adopt two-stage damping, install adjustable elastic suspension damping seat, driving comfortable.
• LTD733H uses electric control proportonal pump, good driving performance, light control.
• Hydrostatic rear wheel drive, stepless speed change, One joystick operation, advanced technology, light and comfortable
operation, safe and reliahle.
• Special vibrating wheel technology, large centrifugal force, high compactness and high working efficiency.
• Articulated frame, light steering, small turning radius, flexible maneuver.
• The rear hood can be turned freely at large angle, Engine inverted, the humanized layout, and the maintenance is within reach.
• Unique appearance modeling, compact structure, low center of gravity, smooth driving, good front and rear view.
• Adopt two-stage damping, install adjustable elastic suspension damping seat, driving comfortable.
• LTD733H uses electric control proportonal pump, good driving performance, light control.
Contact me
Candice Li
Mobile/WhatsApp/Wechat : +86-13599640301
Email : candice@cruking.com
Candice Li
Mobile/WhatsApp/Wechat : +86-13599640301
Email : candice@cruking.com
Product Paramenters
Item | Unit | LTD740H | LTD736H | LTD733H |
Operating weight | kg | 40000 | 36000 | 33000 |
Static linear load | N/cm | 1000 | 900 | 850 |
Vibration amplitude | mm | 2/1.2 | 2/1.2 | 2/1.2 |
Vibration frequency | Hz | 27/31 | 27/31 | 27/31 |
Centrifugal force | kN | 810/510 | 760/560 | 680/590 |
Travel speed | km/h | 8 | 8 | 8 |
Theoretical gradeability | % | 40 | 40 | 40 |
Turning radius | mm | 7500 | 7500 | 7500 |
Overall dimension | mm | 6945*2710*3200 | 6945*2710*3200 | 6945*2710*3200 |
Drum width | mm | 2400 | 2400 | 2400 |
Wheelbase | mm | 3500 | 3500 | 3500 |
Engine Model | - | WP12G375E350 | WP12G375E350 | WP12G375E350 |
Rated power | kW | 276 | 276 | 276 |
