Best selling PLK Crawler Tracked Spider Crane 360 degree 3 Ton 5 Ton Spider Crane hydraulic Spider crane For Construction
- Category: >>>
- Supplier: Jinan Plk Machinery Co. Ltd.
Share on (1601246298086):
Product Overview
Description
PLK LIFT Crawler Spider Crane combines the space-saving qualities of a spider crane with the powerful lifting capabilities of a pick-and-carry crane inside one practical machine. This compa
ct equipment offers an alternate solution to the difficulties associated with lifting in areas with re
stricted access.
Features & Advantages:
1. The Crawler Spider Crane for moving loads quickly, easily, and safely.
2. Spider crane, suitable for occasions with limited space.
3. The spider crane is a full-slewing, boom-type, full-hydraulic transmission crane.
4. The main arm is 4-5 sections. The main arm section adopts a U-shaped structure. The single-st
age telescopic oil cylinder and the wire rope telescopic mechanism can realize the synchronous
expansion and contraction of the main arm.
5. The telescoping limit of the boom uses the double insurance of the marking line and the
alarm
Data Sheet
Model Type | CL1.2 | CL2.0 | CL3.0 | CL5.0 | CL8.0 | CL10.0 | CL12.0/14.0 | ||
Lifting Capacity | 1.2 ton | 2.0 ton | 3.0 ton | 5.0 ton | 8.0 ton | 10.0ton | 12ton / 14ton | ||
Max Lifting Height | 5.8m | 6.8 | 10.5m | 16m | 18m | 21m | 24.5m | ||
Max Working Radius | 5m | 6m | 9.5m | 15m | 17m | 20m | 23m | ||
Winch | Hook rising speed | 0-8m/min | 0-10m/min | ||||||
| Wire Rope | Φ8mm×35m | Φ8mm×35m | Φ8mm×45m | Φ10mm×70m | Φ10mmx80m | Φ11mmx80m | Φ12mmx80m |
|
Heave Device | Boom Angle/Time | 0-75°/13sec | |||||||
Rotary Device | Rotation angle/speed | 0-360°(continuous)/60sec | |||||||
Running gear | way of walking | Hydraulic motor drive | |||||||
| Walking speed | 0-2.5km/h | 0-2.5km/h | 0-5.5km/h | |||||
| Gradeability | 20°(36%) | |||||||
Motor | Voltage | AC 380V | |||||||
Engine | Power | AC + Gasoline (engine brand Honda) | AC+Diesel (engine brand Changchai or Yunnei) | ||||||
| Type/displacement | 9.6 kw | YN27GBZ/2.7L | ||||||
| start method | electric start | |||||||
| boot performance | -5°C~40°C | |||||||
| fuel/volume | Gasoline/8L | Diesel//45L | ||||||
| battery (optional) | 12v 45AH | 24v 45AH | ||||||
Product Description
APPLICATIONS:
Our Services
1.We can design the customerized electric crane as per your requirement.
2.The most suitable model will be recommended to you once we know about your requirement.
3.Shipment can be arranged from our port to your destination port.
4.Opetion video can be sent to you if needed.
5.Maintenance video will be given once the electric crane break down to help you repair.
6.Parts of crane can be sent to you by express within 7 days if needed.
