2025 Good Quality Level A1 Fireproof Glass Magnesium Oxide MGSO4 MGO Board with Low Factory Price for South America Market

Product Overview

Description

SWISSIWS SULFATE (SULPHATE) MGSO4 BOARD

This panel is the most cost-effective fire rated replacement for poured concrete in floors and roof decks as well as walls where

high impact fire rated surfaces are required. It allows rapid installation for accelerated schedules while giving architects and

contractors a sustainable product that is silica free and mold intolerant.



It is very green in comparison to competitive products. While cement based products use tremendous amounts of energy in their

manufacture, SWISSIWS MGO BOARD uses a room temperature process that uses a small fraction of energy in comparison.

With no silica, it does not pose the same threat to workers when cutting or sanding. Its mold resistance is exemplary.



‘Dimension’ of SWISSIWS SULFATE (SULPHATE) MGSO4 BOARD

Sizes:	1220*2440, 1200*2400, 1200*2250, 1200*2280, 1100*2750, 1100*2950, 1100*3000
Thickness:	3mm to 25mm
100% asbestos free	Other specifications available
Thickness tolerance	0.5mm
Size tolerance	2mm



Chart below states general ‘technical parameter’ of SWISSIWS SULPHATE MGSO4 BOARD

Characteristic	Unit	Description
Density	1050KGS/M3	Grams per cubic meter
Tensle Strength	>5.5 (MPa)	Mega pascal units
Compressive Strength	>25 (MPa)	Mega pascal units
Striking Resistant Strength	±23.5 (N/mm2)	Newton per square millimetre
Dimensional Change	0.35 (%)	Percentage of water absorption
Modulus of Elasticity	~6055 (N/mm2)	Newton per square millimetre
Flexibility	~20.5 (N/mm2)	Newton per square millimetre
Thermal Conductivity	~0.153 (W/mK)	High Aust. Insulation Rating
Asbestos	0 %	Absent
Formaldehyde	0 %	Absent
Freeze Thawing Test	/	No change after 15 cycles of freeze Thawing
