screw putty pumping machine KLW mortar spraying machine with mixer for ceiling plaster with mini air compressor
- Category: >>>
- Supplier: Henan Coal Science Research Institute Keming Mechanical And Electrical Equipment Co. Ltd.
Share on (1601255336422):
Product Overview
Description
Product Description
1. KLW Plastering Machine is a multi-functional plastering equipment, widely used for pumping and spraying ready-mixed materials.
2. Engineering grouting: pressure grouting for reservoir, hydropower station, dam, port, wharf; reinforcement grouting for soft foundation; backfill grouting or rock bolting for tunnel, subway, mining well etc.
3. Slurry circulation or mortar backfill in deep mine construction of ground source heat pump.
4. Mortar delivery for weighbridge, masonry and plastering. Mortar delivery and plastering of commercial mortar or other mortar with equivalent performance.
2. Engineering grouting: pressure grouting for reservoir, hydropower station, dam, port, wharf; reinforcement grouting for soft foundation; backfill grouting or rock bolting for tunnel, subway, mining well etc.
3. Slurry circulation or mortar backfill in deep mine construction of ground source heat pump.
4. Mortar delivery for weighbridge, masonry and plastering. Mortar delivery and plastering of commercial mortar or other mortar with equivalent performance.
1. KLW180J Mortar Plastering Machine is a screw type wet plastering equipment.
2. KLW180J Mortar Plastering Machine is composed of a screw pump and air compressor.
3. KLW180J Mortar Plastering Machine has small size and light weight, flexible movement, convenient operation and maintenance.
4. Low noise, high pressure, high capacity, high efficiency, reliable performance, long service life.
2. KLW180J Mortar Plastering Machine is composed of a screw pump and air compressor.
3. KLW180J Mortar Plastering Machine has small size and light weight, flexible movement, convenient operation and maintenance.
4. Low noise, high pressure, high capacity, high efficiency, reliable performance, long service life.
Specification
Model | Spraying distance | Capacity | Power | Aggregate size | Air compressor |
KLW120 | 10m | 100~120m2/h | 4kw | 4mm | 2.2kw (0.3 m³/min) |
KLW120D | 10m | 100~120m2/h | 12hp | 4mm | 0.3 m³/min |
KLL120 | 10m | 100~120m2/h | 4kw | 4mm | 2.2kw (0.36 m³/min) |
KLW150 | 15m | 120~150㎡/h | 5.5kw | 5mm | 3kw(0.36 m³/min) |
KLW150D | 15m | 140~160㎡/h | 15hp | 5mm | 0.36m³/min |
KLW180 | 20m | 150~180㎡/h | 7.5kw | 6mm | 3kw(0.4m³/min) |
KLW180D | 20m | 150~180㎡/h | 18hp | 6mm | 0.4m³/min |
KLW180J | 20m | 150~180㎡/h 3 m³/h | 7.5kw 3kw | 6mm | 3kw(0.4 m³/min) |
Packing & Delivery
Standard export package or customized package
small parts in wooden box
small parts in wooden box
Related machines
Our main machines are : Shotcrete equipment, grouting equipment, mixing equipment, plastering equipment, hose pump etc.
Certifications
In July 2009, the company passed the ISO9001:2008 Quality Management System Certification.
In October 2010, the company was entitled as the “Henan Provincial High-tech Enterprise”.
In 2013, the new wet shotcrete technology was reward the second prize of
Henan Provincial S&T Progress Award.
In 2013, the new wet shotcrete technology was reward the second prize of
Henan Provincial S&T Progress Award.
In December 2014, the brand “KEMING” was awarded the “Henan Provincial Famous Trademark”.
In October 2016, “KEMING” series products have been certified by CE Certification.
In October 2016, “KEMING” series products have been certified by CE Certification.
Why Choose Us
Henan Coal Science Research Institute Keming Mechanical and Electrical Equipment Co. , Ltd is a holding subsidiary of Henan Coal Scientific Research Institute Co., Ltd.
Our company is dedicated to the research and development, production and sales of shotcrete machine, grouting pump, and complementary products. Up to now, we have developed more than 50 kinds of products, covering spraying machines, pumps and other series of products.
Our company is dedicated to the research and development, production and sales of shotcrete machine, grouting pump, and complementary products. Up to now, we have developed more than 50 kinds of products, covering spraying machines, pumps and other series of products.
Achievements: Our company has obtained more than 20 national invention patents and utility model patents, more than 10 scientific and technological achievements appraisal awards, 8 awards from China National Coal Association and Department of science and technology of Henan province, and the second prize of Henan Provincial S&T Progress Award.
Business Scope: As a comprehensive high-tech enterprise, our company is engaged in the research and production of mining machinery, engineering machinery and supporting equipment for underground engineering, as well as environment protection, chemical industry, inspection and testing of mining equipment, research and production of mechanical and electrical products, technology and finance, management and technology consulting service, and other industries.
Business Scope: As a comprehensive high-tech enterprise, our company is engaged in the research and production of mining machinery, engineering machinery and supporting equipment for underground engineering, as well as environment protection, chemical industry, inspection and testing of mining equipment, research and production of mechanical and electrical products, technology and finance, management and technology consulting service, and other industries.
Cooperate Culture:
Enterprise Spirit: Devotion, responsibility, innovation, excellence
Service Concept: Serve consumers and satisfy consumers
Business Philosophy: Cultivate excellent talent, invent superior product, offer perfect service
Enterprise Vision: Lead the machinery manufacturing industry, be an outstanding listed company
Service Concept: Serve consumers and satisfy consumers
Business Philosophy: Cultivate excellent talent, invent superior product, offer perfect service
Enterprise Vision: Lead the machinery manufacturing industry, be an outstanding listed company
Exhibition
Bauma Shanghai 2018
FAQ
1. Q:How to pay for this order?
A:Generally, TT, 30% deposit 70% before shipment； L/C at sight (high bank charge, not suggest, but acceptable);100% TT in advance (especially for small amount and spare parts etc.)
2. Q:How to place an order?
A:Both online order and offline order are acceptable.It is suggested to place online order with a Trade Assurance (Alibaba) to get full protection for this order.
3. Q:How about the package?
A:We have fumigation-free wooden case to protect the machine from damage during the long-distance delivery.
4. Q:What is the lead time?
A:1 week for sample model, 2~3 weeks for customized model. It depends for mass production.
5. Q:What should we do if there are some problems with the machine?
A:You can refer to the Operate Instruction or call our 24-hour service hotline. Also, our engineers are available to service overseas.
6. Q:Do i need technical skills to operate this machine?
A:Yes. Please read the Operation Instruction for some basic technical skills. And, we provide online and onsite technical training if necessary.
2. Q:How to place an order?
A:Both online order and offline order are acceptable.It is suggested to place online order with a Trade Assurance (Alibaba) to get full protection for this order.
3. Q:How about the package?
A:We have fumigation-free wooden case to protect the machine from damage during the long-distance delivery.
4. Q:What is the lead time?
A:1 week for sample model, 2~3 weeks for customized model. It depends for mass production.
5. Q:What should we do if there are some problems with the machine?
A:You can refer to the Operate Instruction or call our 24-hour service hotline. Also, our engineers are available to service overseas.
6. Q:Do i need technical skills to operate this machine?
A:Yes. Please read the Operation Instruction for some basic technical skills. And, we provide online and onsite technical training if necessary.
