State of the Art Freeze Drying Equipment in 5㎡ 10㎡ 20㎡ 30㎡ and 60㎡ for Efficient Food Processing and Preservation
- Category: >>>
- Supplier: Kaifeng Youdo Machinery Co. Ltd.
Share on (1601255385729):
Product Overview
Description
Products Description
Freeze-dryers larger than 60 square meters typically include a drying chamber, refrigeration system, vacuum system, heat media circulation system, automatic control system, pneumatic system, in-place cleaning and sterilization system, water trap or cold trap, trays or shelves, material trays, vacuum pump, piping and valves, safety devices, data recording and traceability system, operating manuals, and software. Additionally, they have quick-freezing storage facility and a conveyor system for efficient material handling.
5㎡ | 10㎡ | 20㎡ | 30㎡ | 60㎡ | |
Model | YDF-Y5M | YDF-Y10M | YDF-Y20M | YDF-Y30M | YDF-Y60M |
Installed Power | 18kw | 34kw | 56kw | 83kw | 145kw |
Size | 3.8*1.2*1.9m | 5.8*1.7*2m | 7.5*1.7*2m | 9*1.7*2m | 7.5m+4*3m+3*3.8m |
Loading capacity (meat products) | About 75~90KG/day | About 150kg/day | About 300kg/day | About 450kg/day | About 800kg/day |
Loading capacity (agricultural products) | About 50~70KG/day | About 100kg/day | About 200kg/day | About 300kg/day | About 600kg/day |
Quantity of each drying bin tray | 16*2 sets | 24 * 2 sets | 48 *2 sets | 72 *2 sets | 144 * 2 sets |
120㎡ | 200㎡ | 240㎡ | |
Model | YDF-Y120M | YDF-Y200M | YDF-Y240M |
Installed Power | 320kw(electric heating) 200kw(steam heating) | 421.9kw | 421.9kw |
Size | 320kw(electric heating) 200kw(steam heating) | 17.8*3*3.8m | 19.8*3*3.8m |
Loading capacity (meat products) | 1800kg(Charge capacity) | 2800kg(Charge capacity) | 3300kg(Charge capacity) |
Loading capacity (agricultural products) | 1800kg(Charge capacity) | 2800kg(Charge capacity) | 3300kg(Charge capacity) |
Quantity of each drying bin tray | 288 *2 sets | 504 *2 sets | 1088pieces |
5㎡、10㎡、20㎡、30㎡、120㎡ | 60㎡ | 200㎡、240㎡ | |
Refrigeration system | Fuji Howe (semi-hermetic piston compressor or screw compressor)Italy imported | Taiwan Fusheng | Siemens Germany |
5㎡、10㎡、20㎡、30㎡ | 60㎡ | 120㎡ | 200㎡、240㎡ | ||
Vacuum pump system | Rotary vane pump roots (to maintain vacuum) | Unit (domestic peer benchmarking enterprise) | Screw Roots unit (domestic peer benchmarking enterprise) | Zhejiang Vacuum Group | |
Pre-pumping unit; ZJP-1200 ZJP-600 ZJP-300 SK-40A Maintain the unit; ZJP-600 ZJP-300 SK-6B | |||||
