Flexible composite high pressure conveyor glass fiber reinforced plastic pipe

Product Overview

Description

High Pressure GRE Line Pipes are made by winding and curing at high temperature using high-strength glass fiber rovings as reinforcement and epoxy resin as the base material.Scope of ProductionDiameter:DN40-DN900;Pressure   rating:3.45MPa-34.5MPa.Can be designed and customized according to customers'requirements. Product StandardsAPI  Spec  15HR-2016  Specification  for  High  Pressure  Fiberglass Line PipeSY/T 6267-2018 Specification for  High  Ppressure  Fiberglass  Line PipeApplicationsOil,gas,water  mixture  transport   in   petroleum,petrochemical  and other areas.Co(Pro)ros(uct)io(C)n(ha)rres(acte)ist(ris)nc(cs)e,strong designability,good insulationperformance and convenient installationCompared with the  pipe  of  the  same  specification,the  inner  wall roughness  is  10%of  the  steel  pipe,the  weight  is  30%of the  steel pipe,and the thermal conductivity is 0.6%ofthe steel pipe.
