H Type 220V/380V Vertical Wind Turbine Generator 5KW 10kw 20kw for Home Use
- Category: >>>
- Supplier: Nantong R&x Energy Technology Co. Ltd.Nantong Ltd.
Share on (1601256684057):
Product Overview
Description
You May Like
Specification
Model | RX-HV2 | ||||||||||||
Rated Power | 1000W | 1500W | 2000W | 2000W | 3000W | 4000W | 5000W | ||||||
Max Power | 1200W | 1700W | 2300W | 2300W | 3500W | 4500W | 5500W | ||||||
Blades Length | 1.6M | 1.8M | 2.0M | 2.0M | 2.0M | 2.8m/s | 1.5m/s | ||||||
Wheel Diameeter | 1.2M | 1.2M | 1.4M | 1.4M | 1.4M | 1.8m/s | 10m/s | ||||||
Generator Type | Maglev coreless | Maglev coreless | Iron-core | Iron-core | Maglev coreless | Iron-core | Maglev coreless | ||||||
Include boost drum | No | No | No | Yes | No | No | No | ||||||
Rated Voltage | 24V~220V | 24V~220V | 48V~220V | 48V~220V | 48V~220V | 48V~220V | 48V~380V | ||||||
Start Up Speed | 1.3m/s | 1.3m/s | 1.3m/s | 1.3m/s | 1.5m/s | 1.5m/s | 1.5m/s | ||||||
Rated Wind Speed | 10m/s | 10m/s | 10m/s | 10m/s | 10m/s | 10m/s | 10m/s | ||||||
Cut in wind speed | 2.5m/s | 2.5m/s | 2.5m/s | 2.5m/s | 2.5m/s | 2.5m/s | 2.5m/s | ||||||
Survival Wind Speed | 40m/s | 40m/s | 40m/s | 40m/s | 40m/s | 40m/s | 40m/s | ||||||
Blades Quantity | 3 | 3 | 3 | 3 | 3 | 3 | 3 | ||||||
Blades Material | Aluminium alloy | ||||||||||||
Working Temperature | -40℃~+40℃ | ||||||||||||
Protection Level | IP54 | ||||||||||||
Working environment humidness | ≤90% | ||||||||||||
Altitude | ≤4500m | ||||||||||||
Install Height | 3~12m | ||||||||||||
Overload Protection | Electromagnetic Brake | ||||||||||||
Gross Weight | 45kg | 80kg | 100kg | 120kg | 140kg | 160kg | 180kg | ||||||
Packing List(cm) | 25*37*37 29*30*148 | 31*31*35 184*25*31 | 215*27*25 120*14*65 | 215*27*25 120*14*65 45*45*31 | 215*27*25 120*14*65 | 45*45*31 260*37*25 120*25*70 | 45*45*31 260*37*25 120*25*70 | ||||||
Recommended for
--Household,Garden,Farm,Urban,Rooftop
--Telecom sites
--Rural electrification programs.Island,sentry,island,sight lighting
--Automatic speed reduction protection
--Automatic speed reduction protection
Drawing
Power curve
Project Photos Show
