HC Power Frequency Charging Inverter
- Category: >>>
- Supplier: Guangxi Guiqing Electric Power Technology Co. Ltd.
Share on (1601256887489):
Product Overview
Description
Products Description
GuiKing HS ineverter this series of products use high-efficiency transformers (optional), built-in solar MPPT controller optional (30A-120A), and complementary with mains, solar priority mode, users can set the charging mode according to the use environment,Product integrated management has the advantages of high conversion efficiency, impact resistance, and strong load capacity. Users only need external solar modules and batteries to form an off-grid power generation system.HS is a multi-functional and intelligent inverter control all-in-one machine.It is currently thehighest-end product in industrial frequency inverters.
Product Feature
1.Applicable to 12V/24V/36V/48V system, automatic identification of system voltage, parallel design, and expansion of system capacity.
2. Four-stage charging improves the charging efficiency and improves the
performance of the battery pack.
3. MPPT tracking efficiency can reach 99.5%, charging efficiency 97.5%.
2. Four-stage charging improves the charging efficiency and improves the
performance of the battery pack.
3. MPPT tracking efficiency can reach 99.5%, charging efficiency 97.5%.
4. Effectively extend the battery life, LCD screen and LED indicator display, can view any parameters and operating conditions in real time.
5. Support PC software monitoring, support WlFl4G module expansion to realize app cloud monitoring (optional)
5. Support PC software monitoring, support WlFl4G module expansion to realize app cloud monitoring (optional)
Product Paramenters
MODEL（HC） | GK-HC2000W | |
Continuous Output Power (W) | 2000W | |
Rated input voltage | 12VDC/24VDC/48VDC | |
Mains mode specifications: | ||
Input voltage waveform | Sine wave (mains or generator) | |
Rated input voltage | 100V/110V/120V/220V/230V/240Vac | |
Low voltage shutdown point | 92/184Vac±4% | |
Low pressure recovery point | 97/194Vac ±4% | |
High voltage shutdown point | 127/253Vac±4% | |
High pressure recovery point | 121/243Vac±4% | |
Maximum AC input voltage | 135/270V rms | |
Rated input frequency | 50Hz/ 60Hz (automatic detection) | |
Low voltage recovery point frequency | 40.5+0.3Hz ; | |
Low voltage cut-off point frequency | 40+0.3Hz; | |
High voltage recovery point frequency | 69.5+0.3Hz; | |
High voltage cut-off point frequency | 70+0.3Hz ; | |
Output voltage waveform | Consistent with the input voltage waveform | |
Overload protection | Circuit breaker start | |
Short circuit protection | Circuit breaker start | |
Power Efficiency | >95% | |
Conversion current | 30A | |
Conversion time (Ac to Dc) | 10ms | |
Bypass switching current | Yes | |
Bypass maximum load current | 30A | |
Output voltage waveform | Sine wave | |
Power factor | 0~1.0 | |
Rated output voltage (V) | 120/230Vac | |
Rated output frequency (Hz) | 60/50Hz ± 0.3Hz | |
Automatic tracking main frequency (Hz) | Yes (from the first connection) | |
Output voltage range | ±2% rms | |
efficient | >80% | |
efficient | >80% | |
Overload protection (SMPS load) | (110%<load<125%): disconnect the output voltage after 15 minutes | |
(125%<load <150%) ±10%: disconnect the output voltage after 10 seconds | ||
Load>150% ±10%: Disconnect the output voltage after 20 seconds | ||
Peak capacity(10s) | 6000VA | |
start the motor | 2HP | |
Short circuit protection | Current limit (power off after 10s) | |
Circuit breaker size | 20A | |
Rated DC input voltage | 12V / 24V/48V | |
Minimum DC terminal voltage | 10V/20V/40V | |
Undervoltage warning | 10.5Vdc ± 0.3Vdc （12V power supply） | |
DC input voltage is too low, automatic power off | 10.0Vdc ± 0.3Vdc（12V power supply） | |
Input overvoltagewarning and power failure | 16Vdc ± 0.3Vdc （12Vpower supply） | |
Input overvoltage recovery | 15.5Vdc ± 0.3Vdc（12V power supply） | |
Power saving | load ≦2W | |
Inverter dimensions(Length*width*height) | 420*185*180mm | |
Packing size (length*width*height) | 580*315*305mm | |
Inverter weight | 17KG | |
Packing operating weight | 19KG | |
Product packaging
Factory Profile
FAQ
Q1: What certificates do you have?
A1: All of our products are CE certified and some inverters are ROHS UL certified.
Q2: What is the minimum order quantity if I want you to apply my design to the parameters, appearance, product and logo on the carton?
A2: MOQ50-100 sets for different products.
Q3: Is it OK if I only want a sample OEM and ODM?
A3: Yes, this is possible, but there is a certain percentage OEM fee.
Q4: What about the warranty? If the inverter has a problem in 1 or 2 years, what will you do?
A4: Inverter has two years warranty, during the warranty period, we provide you with free parts replacement, no need to send back to China. After the warranty period, we will provide support, if you need to extend the warranty period, you will need to pay additional warranty fees.
Q5: What happens if I encounter a problem during installation? Would you support that?
A5: Yes, we can help online, regardless of technical service or after-sales service please contact us email or whatsapp.
Q6: If I place an order, how long is the lead time? How soon can you deliver the goods?
A6: For inverters in stock , it takes two weeks to manufacture a new inverter, and ODM,OEM takes 4-5 weeks to customize.
Q7: In addition to inverters, do you also provide other solar supporting products?
A7: Yes, we can provide other solar products according to your requirements.
A1: All of our products are CE certified and some inverters are ROHS UL certified.
Q2: What is the minimum order quantity if I want you to apply my design to the parameters, appearance, product and logo on the carton?
A2: MOQ50-100 sets for different products.
Q3: Is it OK if I only want a sample OEM and ODM?
A3: Yes, this is possible, but there is a certain percentage OEM fee.
Q4: What about the warranty? If the inverter has a problem in 1 or 2 years, what will you do?
A4: Inverter has two years warranty, during the warranty period, we provide you with free parts replacement, no need to send back to China. After the warranty period, we will provide support, if you need to extend the warranty period, you will need to pay additional warranty fees.
Q5: What happens if I encounter a problem during installation? Would you support that?
A5: Yes, we can help online, regardless of technical service or after-sales service please contact us email or whatsapp.
Q6: If I place an order, how long is the lead time? How soon can you deliver the goods?
A6: For inverters in stock , it takes two weeks to manufacture a new inverter, and ODM,OEM takes 4-5 weeks to customize.
Q7: In addition to inverters, do you also provide other solar supporting products?
A7: Yes, we can provide other solar products according to your requirements.
