Deye ESS GE F60 100Ah HV Battery Best Solar Energy Storage LiFePO4 Lithium Ion Battery Rack Deye 10 Years Warranty
- Category: >>>
- Supplier: Greensun Solar Power
Share on (1601257108918):
Product Overview
Description
Product Description
Specification
MODEL | GE-F60 |
Battery Type | LiFePO4(LFP) |
Nominal Voltage | 51.2V |
Nominal Capacity | 100Ah |
Battery Module Qty In Series (Optional) | 12 |
System Nominal Voltage (V) | 614.4 |
System Operating Voltage (V) | 480~700 |
System Energy (kWh) | 61.44 |
Rated DC Power | 61.44kw |
Charge/Discharge Current (A) | Recommend 50A |
Nominal 100A | |
Peak Discharge (2 mins, 25℃) | |
Working Temperature (°C) | Charge: 0~55/Discharge: -20~55 |
Status Indicator | Yellow: Battery High Voltage Power On Red: Battery System Alarm |
Communication Port | CAN2.0/ RS485 |
Humidity | 5%~85%RH |
Altitude | ≤2000m |
IP Rating of Enclosure | IP55 |
Dimension (W/D/H,mm) | 735*1045*2235 |
Weight Approximate (kg) | 1010 |
Storage Temperature (°C) | 0~35 |
Operating Temperature (°C) | -30~45(＞45 derating) |
Recommend Depth of Discharge | 90% |
Cycle Life | 25±2°C,0.5C/0.5C, EOL70%≥6000 |
Warranty | 10 years |
Certification | UN38.3/CB/CE/CEC/IEC62040 |
Details Images
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
