wholesale SLENERGY hybrid inverter solar 6kw 5kw 3.6kw 1 pohase SL6KLV W home system hybrid solar inverter
- Category: >>>
- Supplier: Ningbo Skycorp Solar Co. Ltd.
Share on (1601258494979):
Product Overview
Description
Model | SL3.6KLV-W | SL5KLV-W | SL6KLV-W | ||
PV (DC) | |||||
Recommended Max. Py input Power | 5760 Wp | 8000 Wp | 9600 Wp | ||
Max. Input Voltage | 500 V | ||||
Start-up Voltage | 125 V | ||||
Rated Input Voltage | 370 V | ||||
MPPT Input Voltage Range | 150-430 V | ||||
MPPT Max. Input Current | 18 A | ||||
MPPT Short-circuit Current | 20 A | ||||
No. of MPPT | 2 | ||||
No. of Strings per MPPT | 1 | ||||
Grid (AC) | |||||
Max. Input Apparent Power | 7590 VA | 7590 VA | 9200 VA | ||
Rated Output Power | 3600 W | 5000 W | 6000 W | ||
Max. Output Apparent Power | 3960 VA | 5500 VA | 6600 VA | ||
Rated AC Voltage | L/N/PE 230 V | ||||
Input/Output Voltage Range | 180-300 V | ||||
Rated Output Voltage Frequency | 50/60 Hz | ||||
Input/Output Voltage Frequency Range | (45-55)/(55-65)Hz | ||||
Rated Output Current | 15.7 A | 21.7 A | 26.1 A | ||
Max. Input/Output Current | 33 / 17.2 A | 33/23.9 A | 40/28.7 A | ||
Power Factor (Rated) | >0.99 | ||||
Adjustable Power Factor Range | 0.8 leading .. 0.8 lagging | ||||
Total Harmonic Distortion | <3% (Rated Power) | ||||
Grid Connection Mode | L/N/PE | ||||
AC Load Output (off-grid) | |||||
Rated Output Power | 3600 W | 5000 W | 6000 W | ||
Max. Output Apparent Powen | 3960 VA | 5500 VA | 6600 VA | ||
Rated Output Voltage | L/N/PE 230 V | ||||
Output Voltage Range | 200-240 V | ||||
Rated Output Frequency | 50/60 Hz | ||||
Rated Output Current | 15.7 A | 21.7 A | 26.1 A | ||
Max. Output Current | 17.2 A | 23.9 A | 287 A | ||
Total Harmonic Distortion | <3% (Rated Power) | ||||
On-grid/Off-grid Switching Time | 10 ms | ||||
Battery (Dc) | |||||
Rated Output Power | 3600 W | 5000 W | 6000 W | ||
Max,Charge/Discharge Power | 3600 W | 5000 W | 6000 W | ||
Rated Voltage | 48 V | ||||
Battery Voltage Range | 40-60 V | ||||
Max. Charge/Discharge Current | 90 A | 120 A | 135 A | ||
Communication Port | CAN/RS485 | ||||
Efficiency | |||||
Max. Efficiency | 97.6% | ||||
Max. MPPT Efficiency | 99.9% | ||||
Max. European Efficiency | 96.5% | ||||
Protection | |||||
Integrated Protection | Anti-countercurrent Protection: insulation lmpedance Detection: Photovoltaic Reverse Connection Protection.Input DC Switch; GFCl Leakage Current Detection; Output Short-circuit Protection; Output Overcurrent ProtectiorGrid Monitoring; lslanding Protection; Residual Current Detection; Off-grid Overloac | ||||
Surge Protection | DC Type ll, AC Type ll | ||||
Display and Communication | |||||
Display | LCD+LED+APP | ||||
Communication | RS485, WiFi (Optional) | ||||
General Data | |||||
Dimensions (WxHxD) | 492x400x220 mm | ||||
Weight | 21 kg | ||||
Operating Temperature Range | -25°c..60°C(Greater than 45°c Derating) | ||||
Noise | <35 dB | ||||
Cooling | Smart Cooling | ||||
Installation Style | Wal-mounted | ||||
Protection Rating | IP65 | ||||
Warranty | 5 Years | ||||
Standards Compliance | |||||
Grid Connection | IEC 62116,IEC 61727,NRS 097-2-1, IEC 61683 | ||||
Safety Regulation | EN/IEC 62109-1/2 | ||||
Others | EN/EC 61000-6-1/3 | ||||
FAQ
1.Do you offer sample for testing purpose?Yes,we do offer sample machine for testing.Please specify your requirements when contacting our agents.
2.What certificate do you have for micro inverters?
VDE 4105.EN50549-1.VDE0126-1-1.ABNT NBR 16149, ABNT NBR 16150, ABNT NBR62116.RD1699. UNE 206006 IN, UNE 206007-1 IN, IEEE1547.Please double check with our agents for certificates.
3.Do you support OEM?
Yes, we do support OEM, however, there's requirement on quantities of your order.
4.What kind of shipment do you offer?
We offer land, sea and air freight upon your request. Fees varies.
5.How long does it take to receive goods I ordered?
For samples, the fastest you can receive is within one week. For bulk orders,dates may vary depending on quantity.
