Compactor Machine 8ton 10 Ton Used Vibratory Road Roller Soil Compactor Road Construction Machinery
- Category: >>>
- Supplier: Shandong China Coal Construction Machinery Co. Ltd.Shandong Ltd.
Share on (1601259015061):
Product Overview
Description
Products Description
Introduction of Earthwork Drum Roller Compactor Asphalt Roller Road 10Ton Earth Roller Compactor For Sale
A road roller, also known as a soil compactor, is a kind of equipment for road construction. Road rollers belong to the category of road equipment in construction machinery, and are widely used in the filling and compaction of large-scale engineering projects such as high-grade highways, railways, airport runways, dams, stadiums, etc. Subgrade stabilized soil and asphalt concrete pavement layer. The road roller is suitable for various compaction operations by the gravity of the machine itself, so that the rolled layer will be permanently deformed and compacted. There are two types of road rollers: steel wheel type and tire type.
1. small working radius, can work in a small area, suitable for trench backfilling ;
2. international brand HONDA petrol engine or famous diesel engine, brand name quality assurance, superior performance, easy to start ;zmwm14
3. international brand name American hydraulic transmission unit, stepless speed change, front and rear travel, easy to change direction ;
4. electric engine start, machine vibration electromagnetic clutch control, easier and more convenient operation;
5. international famous NSK bearings, MITSUBOSHI (Samsung) triangle belt, to ensure the working performance of the machine;
6. beautiful surface spraying, rust and corrosion resistant; this product has passed CE certification..zmwm14
1. small working radius, can work in a small area, suitable for trench backfilling ;
2. international brand HONDA petrol engine or famous diesel engine, brand name quality assurance, superior performance, easy to start ;zmwm14
3. international brand name American hydraulic transmission unit, stepless speed change, front and rear travel, easy to change direction ;
4. electric engine start, machine vibration electromagnetic clutch control, easier and more convenient operation;
5. international famous NSK bearings, MITSUBOSHI (Samsung) triangle belt, to ensure the working performance of the machine;
6. beautiful surface spraying, rust and corrosion resistant; this product has passed CE certification..zmwm14
Product Paramenters
Compaction | ||
Static linear load | 285N/cm | |
Nominal amplitude | 1.8mm | |
Vibration frequency | 50Hz | |
Excitation force | 160KN | |
Engine | ||
Model | 4g33TC | |
Type | Diesel water-cooled four-stroke, four cylinders | |
Power | 75kw/2400r/min | |
Fuel tank volume | 130L | |
Lubricating oil volume | 9.6L | |
Fuel consumption | 246g/kw/h | |
Travel | ||
Speed | 0-15km/h | |
Turning radius | 2980mm | |
Theoretical climbing capacity | 55% | |
Size specification | ||
Wheel width | 1850mm | |
Wheel diameter | 1200mm | |
Wheel spacing | 2980mm | |
Overall length | 5100mm | |
Overall width | 2010mm | |
Overall height | 2670mm | |
Package size | 5300*2200*2800mm | |
Compaction | ||
Static linear load | 385N/cm | |
Nominal amplitude | 1.8/0.44mm | |
Vibration frequency | 70Hz | |
Excitation force | 285/150K | |
Engine | ||
Model | YCD4T33T6-115 | |
Type | Diesel engine water-cooled four-stroke,four cylinders | |
Power | 86kw/2400r/min | |
Fuel tank volume | 75L | |
Lubricating oil volume | 11L | |
Fuel consumption | 285g/kw/h | |
Travel | ||
Speed | 0-15km/h | |
Turning radius | 3100mm | |
Theoretical climbing capacity | 55% | |
Size specification | ||
Wheel width | 2130mm | |
Wheel diameter | 1400mm | |
Wheel spacing | 3160mm | |
Overall length | 5610mm | |
Overall width | 2300mm | |
Overall height | 2700mm | |
Package size | 5800*2400*2810mm | |
