China Made 2 Level Hydraulic Car Storage Lift System Steel Construction Pit Drive Mode Garage Vehicle Hoist for Private Houses

Share on (1601259749101):


Price:$6,121.00 - $14,121.00

Quantity:


Product Overview

Description


I am responsible for the safety of every car!!!










Hydraulic Pit Scissor parking Lift








Features


1.High quality of bearings ensure long service life.


2.Manual oil drain valve to lower platform when power off.


3. Integrated Hydraulic pumping station to save space and reduce the leakage of oil.


4. Hydraulic pipe system: The entire system of fluid conductors such as hose, pipe, tubing.


5. Operation electric box with emergency switch and Dead Man push buttons with Switch Key.


6. Base frame with U channels to guide sliding blocks / rollers during rising up & Lowering down.


7.Hose burst/ rupture valve located at hydraulic cylinder to prevent back flow of pressurized oil in the system after the valve.


Parameter



















































Model No.



QBS50



QBS100



Lifting capacity



5000 Kg



10000 Kg



Self closed height



850 mm



850 mm



Lifting height



2400 mm



2400 mm



Platform size



5600*2700 mm


(Customized)



5600*2700 mm (Customized)



Hydraulic cylinders



4 pcs high precision wearable cylinders



4 pcs high precision wearable cylinders



Safety device



Limit switches,cracking hose /rupture valve



Limit switches,cracking hose /rupture valve



Voltage/Motor capacity of power unit



380V/50Hz/3Ph/5.5Kw



380V/50Hz/3Ph/5.5Kw



Surface treatment



Advanced anti-corrosion painting



Advanced anti-corrosion painting















FAQ





Q: Are you a factory or trading company?


A: Qingdao Lifter Machinery Co., Ltd is a factory with more than 30 years’ manufacturing and design experience.


Q: Could the parking system be customized?


A: Yes. The parking system can be customized accordingly to your site and requirements.


Q: Could the parking system be used for parking SUV?


A: Yes.The system can be customized to fit for SUV. Please contact us for more details.


Q: Could the system be used outdoor?


A: Yes. The structure surface is galvanized or painted, which is water-proof, and extra covers could be installed to prevent from rain, snow and heavy wind.


Q: What's the voltage requirement?


A: The voltage can be customzied accordingly to your local voltage.
