Blue schist waterproofing membrane SBS modified torch on felt

Product Overview

Description

                     SBS modified bitumen waterproofing membrane

                             Polyester/Fiberglass reinforced



Description:

SBS/APP waterproof membrane is made of modified asphalt through scientific process with heat transfer oil as carrier.



It has such advantages as no flow under high temperature condition, being soft under low temperature condition, being high flexible and aging resistant.



Thus the flex durability, flexibility and cohesive force of the asphalt is largely improved.



Therefore, the waterproof quality of the buildings improves a lot and service time also prolongs.







Specifications:



1. Type: Type I, Type II



2. Base felt: PY/G



3. Upper surface material: PE/Sand/Mineral/Al



4. Thickness: 2mm-5mm or according to customer’s requirement







Usage:



SBS/APP modified asphalt waterproofing membrane can be widely used for building surface and basement waterproof in industrial and civil engineering, as well as waterproof for subway, cold storage, airport runway and viaduct.







SBS modified asphalt waterproofing membrane is specially suitable to the architecture’s waterproofing in cold area and to the building of unstable constructions, while APP specially is suitable to areas of high temperature and of strong sunshine.







Application areas:



1. Balcony, bathroom, kitchen



2. Tunnels, Industrial roofs



3. Flat and sloped roofs



4. Basements, Foundation and retaining walls



5. Gardens, Bridges





Item	SBS/APP modified asphalt waterproof membrane
Brand	Jianda
Type	I		II
Base felt	PY		G
Surface	PE	S	M	Al
Thickness	2/3/4/5mm or according to customer’s requirement
Color	Black PE film	Yellow/green/other Fine Sand	Grey/Green/other Mineral Grains/Flakes		Aluminium Foil
Notes	PY------Polyester Base         S------Fine sand  G-------Fiberglass Base         M------Mineral granules



Description	Width	Length	Thickness	Weight
SBS modified bituminous sheet materials(PE)	1m	10m	2mm	28kg/roll
	1m	10m	3mm	41kg/roll
	1m	8m	4mm	45kg/roll
SBS modified bituminous sheet materials with mineral granules(M)	1m	10m	3mm	45kg/roll
	1m	8m	4mm	47kg/roll
	1m	8m	5mm	57kg/roll
SBS modified bituminous sheet materials with aluminum foil(Al)	1m	10m	2mm	29kg/roll
	1m	10m	3mm	42kg/roll
	1m	8m	4mm	46kg/roll
Self-adhesive polymer modified bituminous waterproof sheet	1m	15m	1.5mm	25kg/roll
	1m	10m	2.0mm	26kg/roll
	1m	10m	2.5mm	32kg/roll
	1m	10m	3.0mm	38kg/roll



Features and advantages:



1. High impermeability, high tensile strength, high extension coefficient

2. Puncture resistance, tear resistance, anti-corrosion, mildew resistance

3. SBS is suitable for lower temperature area, while APP is suitable for higher temperature area

4. Perfect durability, service life can up to 30 years

5. Flexible install method: Either by heating and melting method, or cold-adhesive method. Either single or multiple layer.

6. No flow, no dripping in higher temperature;

  No crack in lower temperature







Installation:



1) Make sure the roof deck smooth, clean and dry (Moisture <9%), then coat the surface of your roof deck with a kind of bitumen paint till dry to start installation.







2) Two ways in installation:







First, heating and melting method----Heat the PE film of the membrane and roof deck surface by heating and melting method to nearly melted (not flowing), then install the membrane fully bonded to the roof deck with overlaps of 5-10cm.







Second, cold-adhesive method-----Pour the cold adhesive homogeneously on the roof deck, the roll the membrane to install it to be fully stick to roof deck.







3)  After installation, a full serious inspection is required to make sure no air bubble, no fold, no falling away to guarantee the waterproof life.







Package, transportation and storage:



1. Packed by plastic bag or adhesive tape.



2. During transportation and storage, keep the package well , put them in a dry airy place, keep away from direct sunlight, acids, alkalis, oil and organic solvents.



3. The shelf life is 12 months under normal storage and transportation conditions. After that period, the product can still be used if it complies with all the items in the specification.
