Deye NEW MODEL SUN 3.6/5/6/7/7.6/8K SG05LP1 EU SM2 3.6k 5k 6k 7k 7.6k 8k Single Phase Hybrid Inverter
- Category: >>>
- Supplier: Changzhou Midfine New Energy Tech Co. Ltd.Changzhou Ltd.
Share on (1601261006614):
Product Overview
Description
* Colorful touch LCD, IP65 protection degree
* AC couple to retrofifit existing solar system
* AC couple to retrofifit existing solar system
* Max. 16 pcs parallel for on-grid and off-grid operation; Support multiple batteries parallel
* Max. charging/discharging current of 190A
* Max. charging/discharging current of 190A
* 6 time periods for battery charging/discharging
* Support storing energy from diesel generator
* Support storing energy from diesel generator
Model | SUN-3.6/5/6K-SG05LP1-EU/8K-SG01LP1-EU | ||||||
Battery Type | Lead-acid or Lithium-ion | ||||||
Battery Voltage Range (V) | 40-60 | ||||||
Max. Charging Current (A) | 190 | ||||||
Max. DC Input Power (W) | 10400 | ||||||
Rated AC Input/Output Active Power (W) | 8000 | ||||||
Rated AC Input/Output Current (A) | 36.4/34.8 | ||||||
MPPT Voltage Range (V) | 150-425 | ||||||
No.of MPPT Trackers/No.of String PerMPPT Tracker | 2/2+2 | ||||||
MAX.efficiency | 97.6% | ||||||
Communication Interface | RS485/RS232/CAN | ||||||
Ingress Protection(IP) Rating | IP 65 | ||||||
Cabinet Size (WxHxD mm) | 366×589.5×237 (Excluding Connectors and Brackets) | ||||||
Weight (kg) | 26.8 | ||||||
Sun 3-6kw single phase SG04LP1 EU SM1/2
SUN-3/3.6/5/6K-SG04LP1-EU-SM1/2 | 3-6kW | Single Phase | 2 MPPT | Hybrid Inverter | LV Battery Supported
Sun 3.6-8kw single phase SG05LP1 EU
SUN-3.6/5/6/7.6/8K-SG05LP1-EU-SM2 | 3.6-8kW | Single Phase | Hybrid Inverter | LV Battery Supported
Sun 3-12kw three phase SG05LP3 EU
SUN-3/4/5/6/8/10/12K-SG05LP3-EU-SM2 | 3-12kW | Three Phase | 2 MPPT | Hybrid Inverter | LV Battery Supported
Sun 14-20kw three phase SG05LP3 EU
SUN-14/15/16/18/20K-SG05LP3-EU-SM2 | 14-20kW | Three Phase | 2 MPPT | Hybrid Inverter | LV Battery Supported
Sun 3-6kw single phase SG04LP1 EU
SUN-3/3.6/5/6K-SG04LP1-EU | 3-6kW | Single Phase | 2 MPPT | Hybrid Inverter | LV Battery Supported
Sun 3.6-6kw single phase SG03LP1 EU
SUN-3.6/5/6K-SG03LP1-EU | 3.6-6kW | Single Phase | 2 MPPT | Hybrid Inverter | LV Battery Supported
Sun 3.6-8kw single phase SG05LP1 EU
SUN-3.6/5/6/7.6/8K-SG05LP1-EU | 3.6-8kW | Single Phase | 2 MPPT | Hybrid Inverter | LV Battery Supported
Sun 7.6-8kw single phase SG01LP1 EU
SUN-7.6/8K-SG01LP1-EU | 7.6-8kW | Single Phase | 2 MPPT | Hybrid Inverter | LV Battery Supported
Sun 5-12kw three phase SG04LP3 EU
SUN-5/6/8/10/12K-SG04LP3-EU | 5-12kW | Three Phase | 2 MPPT | Hybrid Inverter | LV Battery Supported
Sun 7.6-12kw single phase SG02LP1 EU
SUN-7.6/8/10/12K-SG02LP1-EU-AM2/AM3 | 7.6-12kW | Single Phase | 2 MPPT | Hybrid Inverter | LV Battery Supported
Sun 12-16kw single phase SG01LP1 EU
SUN-12/14/16K-SG01LP1-EU | 12-16kW | Single Phase | 3 MPPT | Hybrid Inverter| LV Battery Supported
Sun 5-25kw three phase SG01HP3 EU
SUN-5/6/8/10/12/15/20/25K-SG01HP3-EU-AM2 | 5-25kW | Three Phase | 2 MPPT | Hybrid Inverter | HV Battery Supported
