Chassis | 1U rack |
Model | poweredge R660xs |
CPU | Two 4th Generation Intel® Xeon® (Socket E) processors |
Memory | 32 DDR5 DIMM slots supports RDIMM 8 TB max, speeds up to 4800 MT/s. |
Storage controllers | Internal: PERC H965i, PERC H755, PERC H755N, PERC H355, HBA355i External: HBA355e Software RAID: S160 BOSS-N1 |
Drive Bays | Front bays: Front bays: ● Up to 8 x 2.5-inch NVMe SSD max 122.88 TB ● Up to 10 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 153.6 TB Rear bays: ● Up to 2 x 2.5-inch SAS4/SATA (HDD/ SSD) max 30.72 TB |
Power Supplies | ● 1800 W Titanium 200-240 VAC or 240 HVDC ● 1400 W Platinum 100-240 VAC or 240 HVDC ● 1100 W Titanium 100-240 VAC or 240 HVDC ● 1100 W LVDC -48 - -60 VDC ● 800 W Platinum 100-240 VAC or 240 HVDC ● 700 W Titanium 200-240 VAC or 240 HVDC Hot swap PSUs with full redundancy. |
Fans | Standard (STD) fans /High performance Gold (VHP) fansUp to 4 sets (dual fan module) hot plug fans |
Dimensions | H– 42.8 mm (1.68 inches) W– 482 mm (18.97 inches) D – 822.88 mm (32.39 inches) with bezel 809.04 mm (31.85 inches) without bezel |
Embedded NIC | 2 x 1 GbE LOM card (optional) |
GPU Options | Up to 3 x 75 W SW |
Warranty | 3 Years |
