Full Automatic Spray Etching Machine Printed Circuit Board Experiment Vocational Educational School Laboratory Equipment
- Category: >>>
- Supplier: Jinan Minrry Technology Equipment Co. Ltd.
Share on (1601264716423):
Product Overview
Description
Company Profile
Recommended Products
Certifications
Products Description
I.Technical Specifications
Horizontal working type: system can simulate horizontal type equipment of manufacturing enterprise, staff only need put board and fetch board. It adapt electrification control panel, easy to use, concise, high safety performance. It adapt double filtration system, spray pump with filtration device, with the addition of dedicated filtration device, it can
strict avoid the impurity in the corrosive liquid jam the nozzle. It adapt dedicated smart model acid and alkali resistant gearing, roller shaft and nozzle adapt full combined type installation, is easy to disassembly and maintain. MRPCB20 Full-Automatic Spray Etching Machine Printed Circuit Board Experiment Vocational Training PCB Teaching Equipment
Effective etching area: width 400mm, length unlimited, min dimension: 40mmX40mm
Machine adapt high strength PVC structure material, it has excellent antiseptic property.
Internal metal piece all use titanium material, any module all can apply to each processing step.
strict avoid the impurity in the corrosive liquid jam the nozzle. It adapt dedicated smart model acid and alkali resistant gearing, roller shaft and nozzle adapt full combined type installation, is easy to disassembly and maintain. MRPCB20 Full-Automatic Spray Etching Machine Printed Circuit Board Experiment Vocational Training PCB Teaching Equipment
Effective etching area: width 400mm, length unlimited, min dimension: 40mmX40mm
Machine adapt high strength PVC structure material, it has excellent antiseptic property.
Internal metal piece all use titanium material, any module all can apply to each processing step.
Product Paramenters
Etching thickness | 0.1mm-4mm | ||||||
Etching temperature | 0-60degree | ||||||
Voltage | 380V, power 3KW | ||||||
Weight | 100KG | ||||||
Dimension 1200X600X800mm | 1200X600X800mm | ||||||
MRPCB20 Full-Automatic Spray Etching Machine Printed Circuit Board Experiment Vocational Training PCB Teaching Equipment
High-power antiseptic water pump, reach up to five kilogram spray pressure, the configuration is complete according to actual production field. The exit and entrance of each step is equipped with sensor for testing and guiding next action of process. Energy conservation and environment protection.
Transfer speed: 0-10M/MIN, it can arbitrary adjustable.
Etching thickness: 0.1mm-4mm
Etching temperature: 0-60degree can arbitrary adjustable.
Etching liquid: acidity or alkaline is OK
Power supply: single module AC380V/3Kw
Etching min line width/ line space: 4mil
Temperature control accuracy: +/-1℃
Voltage: 380V, power 3KW
Package, wood package, dimension 1200X600X800mm. Weight 100KG
Acidity etching liquid and alkaline liquid 100L.
The main components of acidity etching liquid is copper chloride solution.
The main components of alkaline etching liquid is ammonium hydroxide solution.
