LNA Cracking Value 300cc Water Cooled Utv Gasoline Engine
- Category: >>>
- Supplier: Wuhan Lna Machinery Equipment Co. Ltd.Wuhan Ltd.
Share on (1601265710559):
Product Overview
Description
Product Description
Specification
Model Number | LNA-G300 | Engine | 300cc |
Size | 2630*1457*1426mm | Top speed | 70-80km/h |
Clutch | Automatic | Start | Electric |
Wheelbase | 1980mm | Cooling | Oil cooled |
Weight | 380kg | Max weight load | 200-300kg |
Front track | 278 | Rear track | 177 |
Battery | 12v,12AH | Fuel Tank | 21L |
Brake | Hydraulic Disc Brake | Wheels | 22*11-10 |
Compression ratio | 9:1 | Minimum turning radius | 3.5m |
Color | Black,Green,Red etc | Packing size | 2300*1460*865mm |
Engine model | 300cc Shaft drive | Clearance | 285mm |
Engine type | 4 stroke |
Detailed Pictures
Driver Seat
The roomy driver-seat provides spacious space for the riders, the knees and legs will be comfortable when drive.
Electric start and Lights
Full Lights and switches including steering lights and head lights etc.
The Sporty Seats
The sporty seater with 5-points seat belts,provides much more safety when drive
Automatic Gear lever
D / N / R Gears
Hand Brake
333
Pedals
Throttle and Brake
Buggy Rear
with Steering lights and Brake light
The Integrated Shaft Drive System
Integrated shaft drive system from inside of engine straight.
Compare to other kind of combined shaft driving system ( engine power comes to chain first, chain drives shaft , shaft drives wheels, powers finally delivered to wheels in 3 times),the integrated shaft drive has much more better power delivery capacity and less power loses on wheels.
Integrated shaft drive has 60% better power delivery efficient then old combined shaft driving system.
The Integrated Shaft Drive System
The Independent Suspensions
The Independent Suspensions
AT 22 x 11 Extra Wide Wheels with Hydraulic Disc Brake
The AT 22 x11 super wide wheels offers absolutely wonderful grip when drive in mud or off road,better performance guaranteed.
Hydraulic Disc Brake in Front
Certifications
Product packaging
Packing and Delivery
LNA always providing high efficiency delivery services to our customers.
Recommend Products
Company Profile
About us
Wuhan LNA Machinery Equipment Co.,Ltd. Established in 2017,is a professional manufacturer and exporter that is concerned with the design,development and production of ATVs and Buggies.all of our products comply with international quality standards just as CE etc,and are greatly appreciated in a variety of different markets throughout the world.As a result of our high quality products and outstanding customer service,we had gained a global sales network reaching North America and Europe and Southeast Asia.
