YHZM 100 Electric Efficient Concrete Mixing Machine Newly Released Batch Plant Use Construction Cement Silo Manufacturing

1. Mixing system: Equipped with high wear-resistant alloy mixing arm with High performance and impact resistance
2. Dosing system: Automatic and precise dosing with high speed and simple operation Simple and strong control function
3. Smooth operation of the conveying system, automatic and centralized control: continuous conveying, etc.
4. Measuring system: Water, cement powder and admixture are measured by electronic scale: precise dosage and solid structure
5. Weighing system: water, cement powder, and admixture are measured by electronic scale: precise dosage and solid structure.
6.Control system: remote management, intelligent control, equipment with alarm correction, operation monitoring, and other functions.

Product Parameter

Model specification

YHZM25

YHZM35

YHZM50

YHZM60

YHZM75

YHZM90

YHZM120

Model specification

JZM500

JZM750

JZM1000

JZM1000

JZM1500

JZM1500

JZM2000

Discharge capacity (L)

500

750

1000

1000

1500

1500

2000

Feed capacity (L)

800

1200

1600

1600

2400

2400

3200

Productivity (m³/h)

25

35

50

60

75

90

120

Stirring motor power (Kw)

5.5*2

5.5*2

7.5*2

7.5*2

11*2

11*2

15*2

Water pump power (Kw)

2.2

2.2

2.2

2.2

2.2

2.2

2.2

Water supply accuracy

Error ≤ 2%

Error ≤ 2%

Error ≤ 2%

Error ≤ 2%

Error ≤ 2%

Error ≤ 2%

Error ≤ 2%

Mixer drum speed (r/min)

14-17

14-17

14-17

14-17

14-17

14-17

14-17

Maximum aggregate particle size (mm)

60/80

60/80

60/80

60/80

60/80

60/80

60/80
