Model | volume (cc) | Filling Weight(g) | Diameter (mm) | Length (mm) | Length Weight (g) | Bursting pressure(Mpa) | Water Temperature Test (℃) | Mouth Connection |
ZH18-12 | 14 | 12 | 18.6 | 84 | 45 | 45 | ≤60 | No thread |
ZH21-12 | 18 | 12 | 21.8 | 88 | 70 | 45 | ≤60 | No thread |
ZH21-28 | 42 | 28 | 21.8 | 160 | 117 | 45 | ≤60 | No thread |
ZH21-45 | 61 | 45 | 21.8 | 248 | 225 | 45 | ≤60 | No thread |
ZH25-16 | 25 | 16 | 25.4 | 95 | 90 | 45 | ≤60 | 3/8-24UNF |
ZH25-20 | 32 | 20 | 25.4 | 107 | 105 | 45 | ≤60 | 1/2-20 UNF |
ZH25-33 | 45 | 33 | 25.4 | 138 | 135 | 45 | ≤60 | 1/2-20 UNF |
ZH30-30 | 50 | 33 | 30 | 120 | 155 | 45 | ≤60 | 5/8-18 UNF |
ZH30-38 | 60 | 38 | 30 | 138 | 180 | 45 | ≤60 | 1/2-20 UNF |
ZH40-60 | 95 | 60 | 40 | 138 | 275 | 45 | ≤60 | 5/8-18 UNF |
Model | volume (cc) | Filling Weight(g) | Diameter (mm) | Length (mm) | Gross Weight (g) | Bursting pressure(Mpa) | Water Temperature Test (℃) | Mouth Connection |
ZH40-75 | 110 | 75 | 40 | 150 | 450 | 250 | ≤60 | M16*1.5 |
ZH40-80 | 130 | 85 | 40 | 174 | 500 | 250 | ≤60 | M16*1.5 |
ZH40-105 | 170 | 105 | 40 | 209 | 600 | 250 | ≤60 | M16*1.5 |
ZH51-155 | 240 | 155 | 51 | 187 | 700 | 250 | ≤60 | M16*1.5 |
ZH51-260 | 350 | 260 | 51 | 295 | 1400 | 250 | ≤60 | M16*1.5 |
