Items | Unit | Specifications |
PON standard. | EPON IEEE802.3ah, GPON ITU-T G.984.x | |
Optical interface | SC/PC connector,1 GPON/EPON interface(EPON PX20+ and GPON Class B+)Receiving sensitivity: ≤-28dBmTransmitting optical power: 0~+4dBmTransmission distance: 20KM | |
Speed | Gbps | GPON: uplink 1.25Gbps, downlink 2.5Gbps; EPON: symmetric 1.25Gbps |
Wavelength | nm | Tx1310, Rx 1490, CATV 1550 |
Interface | data | 2*GE 10/100/1000Mbps Auto adaptive Ethernet interfaces, Full/Half Duplex, RJ45 connectors |
Wireless | Compliant with IEEE802.11b/g/n/ac 2.4GHz Operating frequency: 2.400-2.483GHz (WiFi 4) 5.0GHz Operating frequency: 5.150-5.825GHz (WiFi 5 wave 2) WiFi:4*4 MIMO,,5dBi antenna, rate up to 1.167Gbps,Multiple SSID TX power: 11n--22dBm/11ac--24dBm | |
USB interface | USB 3.0, Transmission Rate: 4.8Gbps | |
POTS interface | 1*RJ11 connectors G.711A/G.711U/G.723/G.729 Codec,T.30/T.38/G.711 Fax mode, DTMF Relay | |
Indicator | LED | PWR, PON/LOS, WiFi, FXS(PHONE),LAN1,LAN1, CATV |
Operating condition | ℃ | Operating temp: -5 ~ +55 |
Storing condition | ℃ | Storing temp: -30 ~ +60 |
Humidity | % | 10~90(non-condensing) |
Power supply | V | DC 12V,1.5A adapter |
Power consumption | W | ≤12 |
Dimension | mm | 242mm×154mm×35mm(L×W×H) |
Net weight | Kg | 0.32 |





Catcast Technology Co.,Ltd is a high-tech enterprise which concentrates on the research, manufacture, sale and engineer service of digital TV headend & broadcasting equipments with 18 years history in Chengdu, China. Catcast is building up both domestic and overseas markets while making a good contribution to the TV broadcasting industry. As a TV network investor, we have accumulated a great deal of experience in network operation of cable or wireless digital TV, IPTV, DSNG system as well as transfer analog tv system to digital tv system. Upgrade CATV/MATV to IPTV system. We are always striving for innovation , and keep the principle to do business: The same product , we win the quality. The same quality, we win the price.
