XCM G 130ton XCA130_S All terrain truck crane with cheap price
- Category: >>>
- Supplier: Bigbund (shanghai) Construction Machinery Co. Ltd.
Share on (1601270840972):
Product Overview
Description
HOT PRODUCTS
Product Description
1. The lifting capacity takes the lead in the industry with strong power, the 4-axle extreme 100-ton all terrain crane with high intelligent level.
2. Closed hydraulic system for lifting and slewing system, equipped with large-displacement pump, lifting speed with heavy load highly. Mature double-variable mechanism with fine control tactic, matching perfectly stably.
3. Automatically recommend the most proper working conditions. Searching and setting work condition simply.
4. With first launched multi-mode drive technology in the industry, real-time intelligent control for various working conditions is realized so that the crane has optimized travel state and crane safety and reliability are improved.
5. Axle load monitoring technology: Proper gear (the highest gear engaged) and axle driving mode are matched automatically by axle load monitoring technology, which provides protection for crane safety in traveling.
Main Parameter
| Item | Unit | Parameters | ||
| Dimensions | Outline size | mm | 15259x2750x3950(14.0R25) | |
| (lengthxwidthxheight) | 15259x2750x4000(16.0R25) | |||
| 15259x2850x4000(20.5R25) | ||||
| Wheel base | mm | 2500+1650+2100+1650 | ||
| Track(Front/ Rear) | mm | 2296(14.0R25)/2340(16.0R25)/2308(20.5R25) | ||
| Front/ Rear overhang | mm | 2582/2359 | ||
| Front/ Rear extension | mm | 2161/0 | ||
| Weight | Max. permissible total weight | kg | 60000 | |
| Axle load | 1st axle | kg | 12000 | |
| 2nd axle | kg | 12000 | ||
| 3rd axle | kg | 12000 | ||
| 4th axle | kg | 12000 | ||
| 5th axle | kg | 12000 | ||
| Power | Engine model | —— | OM471LA | |
| Engine rated power/rpm | kW/(r/min) | 360/1700 | ||
| Max. net power/rpm | kW/(r/min) | 360/1700 | ||
| Max. output torque/rpm | N.m/(r/min) | 2300/1300 | ||
| Emission standard | —— | EU Stage IV/EPA Tier 4F | ||
| Main performance | Max. total rated lifting capacity | t | 130 | |
| Min. rated working radius | m | 3 | ||
| Turning radius at turntable tail | Counterweight | mm | 4630/4335 | |
| Auxiliary winch | mm | 4600 | ||
| Max. load moment | Base boom | kN.m | 4468 | |
| Fully-extended boom | kN.m | 2297 | ||
| Fully-extended boom + Jib | kN.m | 1976 | ||
| Outrigger span | Longitudinal | m | 8.35 | |
| Lateral | m | 7.7 | ||
| Hoist height | Base boom | m | 12.1 | |
| Fully-extended boom | m | 61.5 | ||
| Fully-extended boom + Jib | m | 92.5 | ||
| Boom length | Base boom | m | 13.1 | |
| Fully-extended boom | m | 62 | ||
| Fully-extended boom + Jib | m | 94.5 | ||
| Jib offset angle | ° | 0,20,40 | ||
Packaging & Shipping
We have made remarkable achievements in maritime transportation. Over the past decade, we have been taking customer satisfaction as our goal, keeping the goods intact as our duty, cooperating with the shipping industry, paying close attention to the logistics process and ensuring that customers receive the goods on time.
Company Information
In order to meet the requirements of different countries for emission standards, our company and products have relevant certificates issued by authoritative agencies, you can buy at ease.
Advantage:
1:Over 10 Years'Foreign Trade Experience
2:Rich experience in sea transportation
3:Professional and enthusiastic salesman
Our Exhibition
Our company will participate every year to exhibit our products. At the exhibition, we will receive overseas online customers and cooperate on the spot. We will actively provide services to customers.
Our Services
pre-sale serviceDear friends, before the sale, we will fully understand your needs, according to your machine requirements and your budget, choose the right model for you, to ensure that you buy high-quality products at a lower price.
At the same time, you are welcome to visit our factory in Shanghai, China, we will book hotels, air tickets and take you to the scenery of Shanghai in advance.
At the same time, you are welcome to visit our factory in Shanghai, China, we will book hotels, air tickets and take you to the scenery of Shanghai in advance.
After-sale service
After the sale, we will properly arrange the transportation of the machine to ensure that the goods are safely delivered to your hands.
At the same time, we will provide you with technical support 24 hours a day, or send engineers to guide the installation and operation. If there are any quality problems with the machine, we will solve it for you in the first time.
At the same time, we will provide you with technical support 24 hours a day, or send engineers to guide the installation and operation. If there are any quality problems with the machine, we will solve it for you in the first time.
FAQ
Q1:Which country do you export to?
Asia:India,Philippines,Thailand,Burma,Vietnam,Bangladesh,Kazakhstan,Turkmenistan,etc.
Middle east:Saudi Arabia,UAE,Jordan,Oman,Pakistan,etc.
Europe:Russia,Ukraine,Belarus,Bulgaria,etc.
Africa:South Africa,Kenya,Congo,Ethiopia,Nigeria,Ghana,Algeria,Senegal,Tunisia,etc.
South America:Brazil,Peru,Chile,Cuba,Venezuela,Mexico,etc.
Oceania:Papua New Guinea,Australia,etc.
Q2:What is the proportion of your products export?
75% of our products are exported to all over the world.
Q3:What is the payment term?
Payment term is negotiable and there will be favorable payment terms for long-term customers.TT,L/C,D/P,depending on the cooperation time,country and contract value.
Q4:What kind of logistic service do you supply?
FOB,CIF,DAP,ETC.
Contact us
send message or chat with me now!
♥When sending an inquiry, please let us know
the type, chassis, engine and other requirements you need.
↓↓↓
