60 series 1.8° two phase open loop stepping motor
60 series 1.8° two-phase open loop stepping motor
60 series 1.8° two-phase open loop stepping motor

60 series 1.8° two phase open loop stepping motor

Share on (1601271309322):


Price:$14.45 - $16.00

Quantity:


Product Overview

Description



Product Paramenters


Item
Specifications
Step Angle Accuracy
±5%（full step, no load)
Resistance Accuracy
±10%
Inductance Accuracy
±20%
Temperature Rise
80℃ Max.(rated current ,2 phase on)
Ambient Temperature
-10℃+50℃
Insulation Resistance
100mΩ Min.@500V DC
Dielectric Strength
1 minute @ 500V AC.5mA
Shaft Radial Play
0.06 Max.@450g
Shaft Radial Play
0.08 Max.@450g



Specification


Item
Unit
OT-60HS88-001
1
Step Angle
°
1.8
2
Length
mm
87
3
Rated Current
A
4.0
4
Resistance
Ω
0.65
5
Holding Torque
gf.cm
30000
6
Inductance
mH
1.9
7
Drive Sequence
Single/Bipolar
bipolar
8
Rotor inertia
g.cm²
1200
9
Weight
g
1400
