DONGFENG 4*4 Truck with Crane All Terrain Hydraulic Truck Crane Cheap 12 Ton Lorry Crane Truck Mounted
DONGFENG 4*4 Truck with Crane All Terrain Hydraulic Truck Crane Cheap 12 Ton Lorry Crane Truck Mounted
DONGFENG 4*4 Truck with Crane All Terrain Hydraulic Truck Crane Cheap 12 Ton Lorry Crane Truck Mounted
DONGFENG 4*4 Truck with Crane All Terrain Hydraulic Truck Crane Cheap 12 Ton Lorry Crane Truck Mounted
DONGFENG 4*4 Truck with Crane All Terrain Hydraulic Truck Crane Cheap 12 Ton Lorry Crane Truck Mounted
DONGFENG 4*4 Truck with Crane All Terrain Hydraulic Truck Crane Cheap 12 Ton Lorry Crane Truck Mounted
DONGFENG 4*4 Truck with Crane All Terrain Hydraulic Truck Crane Cheap 12 Ton Lorry Crane Truck Mounted

DONGFENG 4*4 Truck with Crane All Terrain Hydraulic Truck Crane Cheap 12 Ton Lorry Crane Truck Mounted

Share on (1601271969949):


Price:$32,400.00 - $32,500.00

Quantity:


Product Overview

Description



Product Overview


Truck with Crane
truck with crane official name: truck with crane transport vehicle, it is widely used in municipal construction, coal mine engineering, landscaping and other infrastructure materials and other equipment lifting and transportation. The crane can be operated left and right, can be rotated 360 degrees, can also be rotated in all directions. Adopt military quality production, reliable quality, long life, fast working speed. Related models are 2 tons, 3.2 tons, 4 tons, 5 tons, 6.3 tons, 8 tons, 10 tons, 12 tons, 16 tons, 18 tons, 20 tons, 25 tons, 30 tons, 80 tons, 140 tons, crane to choose from, you can choose straight arm or folding arm crane.
truck with crane is a transport vehicle combined with a truck crane and a chassis. It is composed of lifting arm, turntable, frame, leg and other parts. The mechanical action of the crane is realized through the action of the mechanism such as amplitude variation, expansion, rotation and lifting, and the lifting operation is realized through the combination of different actions.


FEATURES AT A GLANCE


It is widely used in the lifting and transportation of municipal construction, coal mine engineering, landscaping and other infrastructure materials and other equipment. The crane can be operated left and right, can be rotated 360 degrees, can also be rotated in all directions. Adopt military quality production, reliable quality, long life, fast working speed.


Right elevation
Left elevation
Side elevation


PRODUCT SPECIFICATIONS


No
Item
Data
1
Overall dimension (L×W×H)(mm)
7860*2400*3250
2
Chassis manufacturer
DONGFENG
3
Drive type
4*4
4
Transmission
Manual , 8 shift forward and 1 reverse
5
Engine brand & Model
YUCHAI POWER & YC4E200-33
(4 cylinders in line, turbocharged and intercooled)
6
Fuel type
Diesel, Euro 2
7
Tire Spec. & number
10.00R16, 6 pieces with one spare
8
Crane tonnage
12 TON
9
Crane optional configuration
1. portable operating system（operate crane equipment remotely）
2. Dump containers（Convenient loading and unloading of goods）
10
Crane component
1. High-altitude seat
2. Crane operating lever
3. Weighing machine
4. Crane working indicator light
5. Crane jib
6. Hoisting system
7. Hook crane
8. Variable amplitude cylinder
9. Rear bracket
10. Hydraulic fluid chamber
11. Radiator assembly
12. Crane rotating disc
13. Bracket operating lever
Front bracket


PRODUCT CONFIGURATION




Company Profile




Why Choose Us


Chengli Special Automobile Co., LTD.
Chengli Special Automobile Co., LTD. (referred to as "Chengli Special Automobile"), located in the hometown of Shennong, the hometown of ancient music, and the southern suburb of Zengdu District, Suizhou City, Hubei Province, was founded in September 2004, with a registered capital of 100 million yuan. The company has total assets of 1.645 billion yuan, covers an area of 610 mu, and 1,786 employees. The main business scope is technology research and development, manufacturing, sales and service of complete vehicles, special purpose vehicles, new energy vehicles and emergency support vehicles.
The company has passed ISO9001 quality management, ISO 14001 environmental management, ISO45001 occupational health and safety management system certification, after-sales service five-star, 3C mandatory certification, automotive energy conservation and environmental protection certification, automobile exemption certification, American mechanical engineer Asmi (ASME) certification, EU agreement ADR and other management certifications. It has the production qualification of special purpose cars, complete cars, new energy vehicles, truck cranes, truck cranes, fire trucks and so on.
The company's "Cheng Liwei" trademark products sell well in domestic and foreign markets, and export to Nigeria, Ghana, Angola, Bolivia, Chile, Cambodia, Myanmar and other more than 50 countries






CERTIFICATION








FAQ


1. who are we?
We are based in Hubei, China, start from 2004,sell to Africa(35.00%),South America(15.00%),Southeast Asia(15.00%),Mid
East(10.00%),South Asia(10.00%),Oceania(5.00%),Central America(5.00%),Eastern Asia(5.00%). There are total about 1000+ people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production
Always final Inspection before shipment;
3.what can you buy from us?
Garbage truck,Wrecker truck,Truck with crane,Sewage suction truck,Water truck
4. why should you buy from us not from other suppliers?
We are a big Special Automobile manufacturer of 17 year' experince who is appointed by the MIITC, have registered trademark"CHENLIWEI"(CLW). We have passed ISO9001, ISO14001, ISO18001, etc management system, own autonomous trade import and export right
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP,Express Delivery,DAF;
Accepted Payment Currency:USD,EUR,HKD,CNY;
Accepted Payment Type: T/T,L/C,MoneyGram,Western Union;
Language Spoken:English,Chinese,Spanish,Russian
