Electric Go Kart mode SQ 333

Product Overview

Description







1. Ternary lithium energy battery:



   • Outstanding performance and strong durability. After tests such as puncture, collision, and vibration, 80% of the battery capacity can reach 2200 hours/1500 cycles.


   • With a battery capacity of 50Ah, a maximum power of 8kW, and it has three adjustable power levels of 3kW - 5kW - 8kW (can be calibrated according to customer requirements).


   • The endurance time is 55 minutes at 8kW and 115 minutes at 5kW.


   • Adopts a quick-release battery design for convenient and rapid battery replacement.






2. Vehicle-grade forward-developed three-electric system:



   • The motor has a service life of 15 years.


   • The battery capacity is 4.8kWh, with a maximum torque of 50Nm and a maximum speed of 10,000rpm.


   • Adopts racing-grade VCU control strategy, bringing a highly sensitive and linear driving control experience.






3. Balance design:



   • With side-mounted dual batteries and a rear-mounted motor, achieving left-right weight balance.






4. Steering system:



   • Integrated with reverse and acceleration buttons, and equipped with a racing steering column.


   • No steering gap after long-term use, enabling customizable steering parameters and showing differentiated chassis performance.






5. Rear axle system:



   • Adopts a racing hollow rear axle, which is lightweight and high-strength.


   • Equipped with a new ventilated brake disc for high braking efficiency.


   • High transmission ratio to amplify torque.






6. Adjustable seat:



   • The front and rear positions are adjustable with an adjustable stroke of 12cm to meet the needs of different body sizes.


   • Equipped with a four-point seat belt and a roll cage to provide all-round protection for the driver.






7. Adjustable pedals:



   • The front and rear positions of the pedals are adjustable with an adjustable stroke of 10cm, suitable for customers with heights ranging from 150cm to 190cm.


   • The brake and throttle sensors are highly integrated, with sensitive braking and acceleration feedback.






8. Vehicle crash frame:



   • Full-surround PE crash-proof outer frame, which is lightweight, stylish, beautiful, and mechanical.


   • Multiple sections of C-shaped plastic outer frames are spliced together, with superior crash resistance.


   • In the main buffer energy-absorbing device, a guide post is equipped inside the rubber column to limit the collapsing direction of the rubber block.


   • A composite buffer block is equipped at a 45-degree angle, and the front crash block + chute design effectively reduces impact.


   • The front and rear double plates are strengthened to resist impact, protect the driver's safety, protect the frame from deformation, enhance the service life of the frame, and reduce maintenance costs.









1. Integrated reverse function for quick escape from being stuck.


2. One-click acceleration function, experiencing the nitrogen acceleration function in movies, making the game a reality, quickly overtaking the vehicle in front, and bringing a super-strong competitive immersive feeling.
