TCK50 Heavy Duty Multifunctional CNC Metal Lathe Inclined Bed Horizontal Sheet Single Spindle Power Turret Living Tools GSK Used
- Category: >>>
- Supplier: Tengzhou Huashuo Nc Machine Tool Co. Ltd.
Share on (1601272490813):
Product Overview
Description
Detailed technical parameters
Machine tool model | Unit | TCK50 |
Diameter of large turn on the bed | mm | Φ500 |
Diameter of slalom | mm | Φ400 |
Processing length | mm | 500 |
Standard chuck specifications | inches | 8″ |
The X axis stroke | mm | 200 |
The Z axis stroke | mm | 550 |
Spindle speed | rpm | 4200rpm Spindle unit structure |
Spindle speed series | Servo variable speed | |
Spindle end code | A2-6 | |
Main shaft drawpipe inner diameter | mm | Φ65 |
Fast moving speed | m/min | 22 |
Cutting feed rate | mm/min | 1-15000 |
Motor torque in X/Z direction | NM | 8/8（X To take the brake） |
Spindle motor power | KW | M15 |
Tool rod cross section | mm | 25×25 |
Diameter of boring tool rod | mm | Φ32 |
Number of tool tower positions | 8 points | |
Hydraulic tailseat stroke | mm | 350 |
Taper of tailstock sleeve | Morse | MT5# |
Tailseat sleeve travel | mm | 95 |
X/Z directional bidirectional positioning accuracy | mm | 0.016/0.02 |
X/Z direction repeated positioning accuracy | mm | 0.006/0.006 |
Total power capacity | KVA | 20 |
Cutting tank capacity | L | 90 |
Overall dimensions (length x width x height） | mm | 3450×1600×1700 |
The weight | KG | 3800 |
Form of rail movement | Line rail |
The name of the | specifications | Quantity | Brand | Production Place |
Control system | The new generation of 22 | 1set | TAIWAN | TAIWAN |
Spindle unit | Φ200 | 1set | TAIWAN | TAIWAN |
The knife tower | 12 station hydraulic tool tower motor (15 KW)ic tool tower | 1set | SANHE | TAIWAN |
Spindle motor | Servo main motor (15 KW) | 1set | TAIWAN | TAIWAN |
guide | Linear guide 35 | 1set | SHANGYINNNN | TAIWAN |
Ball screw | X3210，z3210 | 1set | SHANGYIN | TAIWAN |
Automatic lubrication | 1set | CHINA | ||
Hydraulic station | 50 l three way | 1set | Nanjing | |
Hydraulic chuck | Hollow 8 "Jia he | 1set | CHINA | |
The hydraulic oil cylinder | Hollow 8" | 1set | CHINA | |
Hydraulic tailstock | Morse 5 | 1set | CHINA | |
Cooling pump | 750w | 1set | CHINA | |
Thermal/electrical box | Di ao te | 1set | CHINA |
Inspection items | Standard tolerance (mm) |
Periodic axial channeling of the spindle | 0.005 |
The spindle chuck locates the radial runout of the cone surface | 0.005 |
The saddle moves the spindle and the tail frame top axis | 0.025 | ||
The rotary tool holder moves laterally against the | 0.010/100 | ||
Location accuracy | repeated positioning accaracy | X：±0.003 Z：±0.005 | |
Positioning accuracy B | X：0.01 Z：0.01 | ||
Precision car external roundness | 0.003 | ||
Consistency of diameter | 0.01/150 | ||
flatness | 0.013/φ200 | ||
Thread pitch product error | 0.010/50 | ||
Surface roughness | Ra1.6μm | ||
