Product Overview
Description
PYB Cone Crusher features compact structure and high production efficiecy.Bowl-shaped bearing is applied for high-precision reservation.It has centralized thin oil lubrication system and new oil sealing dust-proof system. When extraneous matters enters crushing chamber,the spring security device can protect the equipment from being damaged.
This series is usually applied in secondary and tertiary crushing stations.And it is suitable for crushing rocks and ores with hardness medium and above,such as iron ore.copper ore, limestone, quartz, granite, sandstone,etc.
This series is usually applied in secondary and tertiary crushing stations.And it is suitable for crushing rocks and ores with hardness medium and above,such as iron ore.copper ore, limestone, quartz, granite, sandstone,etc.
Model | Max Feed Size(mm) | Adjustable of Discharge Opening(mm) | Crushing Capacity(tph) | Electirc Motor Power(kW) | Speed of Eccentric Shaft(rpm) | Overall Dimension (l*w*h)(mm) | Weight (t) | ||
PYB | 600 | 65 | 12-25mm | 25-40 | 30 | 356 | 2234×1370×1675 | 5.3 | |
PYD | 35 | 3-13mm | 12-23 | 2234×1370×1675 | 5.3 | ||||
PYB | 900 | 115 | 15-50mm | 50-90 | 55 | 333 | 2692×1640×2350 | 11.2 | |
PYZ | 60 | 5-20mm | 50-65 | 2692×1640×2350 | 11.2 | ||||
PYD | 40 | 3-13mm | 14-50 | 2692×1640×2350 | 11.3 | ||||
PYB | 1200 | 145 | 20-50mm | 110-168 | 110 | 300 | 2790×1878×2844 | 24.7 | |
PYZ | 100 | 8-25mm | 42-134 | 2790×1878×2844 | 25 | ||||
PYD | 50 | 3-15mm | 18-105 | 2790×1878×2844 | 25.3 | ||||
PYB | 1750 | 215 | 25-60mm | 280-480 | 155 | 245 | 3910×2894×3809 | 50.3 | |
PYZ | 185 | 10-30mm | 115-320 | 3910×2894×3809 | 50.3 | ||||
PYD | 85 | 5-15mm | 75-230 | 3910×2894×3809 | 50.2 | ||||
PYB | 2200 | 300 | 30-60mm | 590-1000 | 280 | 220 | 4622×3302×4470 | 83 | |
PYD | 100 | 5-15mm | 120-340 | 4622×3302×4470 | 83 | ||||
Zhejiang Gravik Machinery and Equipment Co.,Ltd is a hi-tech, engineering company. We are specialized in the research, development, and production of industrial crushing, powder grinding, mineral processing equipments and Crusher parts field. Our products have been sold to 120 countries and areas of Southeast Asia, East Europe, South America, the Middle East and Africa etc,
Our products field:
1. Crusher machinery: Jaw crusher, Impact crusher, Cone crusher, Grizzly feeder, Vibrating screen, Belt conveyor, sand washing machine etc.
2. Crusher parts: Wear parts for all jaw/cone/impact Crushers/Vibrating screen/ Belt conveyor, include jaw plate, check plate, mantle & bowl liner, blow bar, screen mesh, roller etc. Cover the brands: Mesto, Sanvik, Terex, Telsmith, Hazemag, Kleemann, Trlo, Symons, Shanbao, Gator, Shibang,Shaorui & etc
Our products field:
1. Crusher machinery: Jaw crusher, Impact crusher, Cone crusher, Grizzly feeder, Vibrating screen, Belt conveyor, sand washing machine etc.
2. Crusher parts: Wear parts for all jaw/cone/impact Crushers/Vibrating screen/ Belt conveyor, include jaw plate, check plate, mantle & bowl liner, blow bar, screen mesh, roller etc. Cover the brands: Mesto, Sanvik, Terex, Telsmith, Hazemag, Kleemann, Trlo, Symons, Shanbao, Gator, Shibang,Shaorui & etc
