item | DF10Z-F68 | |
CPU | Processor: RK3568 | |
GPU | CPU: 4-core Cortex-A55 architecture, maximum frequency 2.0GHz | |
NPU | GPU: ARM G52 2EE | |
Memory/Storage | Standard 2G/ EMMC5.1 standard 16G (32G optional) | |
Built-in ROM | 32KB EEPROM | |
Serial port | 1* RS232, 1* RS485, 1* TTL, 1* DO (multiplexed with 485) | |
USB | 2* USB3.0, 1 of which is multiplexed with USB and OTG | |
Audio | 1* two-channel SPK, 4Ω 3W | |
Ethernet | 2* 1000Mbps adaptive network interface | |
WIFI | Standard WiFi 2.4G (5G WiFi optional), Standard BT4.0 | |
4G (optional) | Optional CAT1 4G module; Optional CAT4 4G module | |
GPS (optional) | Channel 1 needs to be replaced with a 4G module with GPS function. Support Beidou and GPS dual positioning | |
SIM card | 1 | |
LED | 1* system indicator light, 1* 4G status indicator light | |
Button | 1* programming button, 1* reset button | |
Power | 1, DC12V±5%/DC24V±5% power supply, DC5.5*2.1MM | |
Overall size | 261.66*198.62*31.5mm | |
Android system | Android 11 | |
Working temperature | -10~60℃ | |
Storage temperature | -20~70℃ | |
Working humidity | 5~90 %RH | |
Storage humidity | 0~90 %RH | |
Screen parameters | ||
Touch screen | 10.1 inch 5 point Capacitive touch | |
LCD screen | 1 0.1 inch | |
Contrast | 900:1 (Typ.) (Transmission) | |
Resolution | 1280(RGB)×800 | |
Screen ratio | 16 : 10 | |
Display color | 16.7M | |
Display brightness | 480-500 cd/m² | |
Working humidity | - 20℃ ~ 70 70℃,≤80% RH | |
Operating temperature | 20℃ ~ 70 70℃,≤80% RH | |
Storage humidity | -30℃ ~ 70 70℃,≤80% RH | |
Storage temperature | - 30℃ ~ 70 70℃,≤80% RH | |
Response time | ≤16ms | |
Normal power | ≤30W | |
Screen pitch | 0.0565×0.1695mm (H×V) | |
