Cone Crusher For Basalt Crushing Concasseur De Pierres Rock Crusher Cone For Sale Chancadora De Piedras
- Category: >>>
- Supplier: Henan Shunzhi Machinery Co. Ltd.
Share on (1601273879686):
Product Overview
Description
Cone crusher is widely used in metallurgical industry, construction materials industry, road building
industry, chemical industry and silicate industry. It is suitable to crush ores and rocks with medium hardness and medium hardness above.
industry, chemical industry and silicate industry. It is suitable to crush ores and rocks with medium hardness and medium hardness above.
It has features of strong crushing force, reliable structure, high efficiency, high capacity, low operation cost, easy adjustment, economical to use and so on. In the medium and large type of cone crusher, multi-cylinder hydraulic locking clearing system can decrease downtime and save the working strength. The PSG series also use the hydraulic locking and machinery which is more reliable. Importantly, every type has several cavity types, the customer can choose different cavity type according to different requirement.
Cone crusher use compensating lubricating grease sealing, which can avoid lubrication oil being polluted by dust, so that all parts work reliably and have a long operating life. The safety insurance system uses spring sets, so the foreign matter and iron ore are down from the crushing cavity and do not damage the crusher,simply and reliably.
VARIOUS MODELS CONE CRUSHER
Multi-Cylinder Hydraulic Cone Crusher
Single Cylinder Hydraulic
Cone Crusher
Spring Cone Crusher
MORE COMBINATIONS CAN BE CUSTOMIZED ACCORDING TO CUSTOMER NEEDS
PRODUCT DETAILS
How the cone crusher works?
When the cone crusher is working, the motor drives the eccentric sleeve to rotate through the V-belt, the large pulley,the transmission shaft, the small bevel gear and the large bevel gear. The surface of the crushing wall sometimes approaches and sometimes leaves the surface of the rolling mortar wall, so that the material is continuously impacted, squeezed and bent and broken in the annular crushing cavity composed of the fixed cone and the moving cone.
SCOPE OF APPLICATION
RIVER PEBBLES
0-10mm
GRANITE
10-20mm
BASALT
20-40mm
MARBLE
40-60mm
40-60mm
TECHNICAL PARAMETERS
Type | Model | Cavity type | Diameter of cone(mm) | Adjusting range of discharge opening (mm) | Max feed size (mm) | Capacity (t/h) | power (kw) | Weight(kg) |
2TT | PSGB-0607 | Standard fine | 600 | 6-38 | 60 | 16-50 | 30 | 4500 |
PSGB-0609 | Standard medium | 10-38 | 80 | 18-65 | ||||
PSGB-0611 | Standard coarse | 13-38 | 90 | 22-70 | ||||
PSGD-0603 | Short head fine | 3-13 | 30 | 9-35 | ||||
PSGD-0605 | Short head coarse | 5-16 | 40 | 22-70 | ||||
3TT | PSGB-0910 | Standard fine | 900 | 9-22 | 85 | 45-91 | 75 | 9980 |
PSGB-0917 | Standard coarse | 13-38 | 150 | 59-163 | ||||
PSGB-0918 | Standard super coarse | 25-38 | 150 | 118-163 | ||||
PSGD-0904 | Short head fine | 3-13 | 35 | 27-90 | 10530 | |||
PSGD-0906 | Short head medium | 3-16 | 65 | 27-100 | ||||
PSGD-0907 | Short head coarse | 6-19 | 85 | 59-129 | ||||
4.25'FT | PSGB-1313 | Standard fine | 1295 | 13-31 | 115 | 109-181 | 160 | 22460 |
PSGB-1321 | Standard medium | 16-38 | 178 | 132-253 | ||||
PSGB-1324 | Standard coarse | 19-51 | 205 | 172-349 | ||||
PSGB-1325 | Standard super coarse | 25-51 | 220 | 236-358 | ||||
PSGD-1306 | Short head fine | 3-16 | 54 | 36-163 | 22590 | |||
PSGD-1308 | Short head medium | 6-16 | 76 | 82-163 | ||||
PSGD-1310 | Short head coarse | 8-25 | 89 | 109-227 | ||||
PSGD-1313 | Short head super coarse | 16-25 | 113 | 118-236 |
OTHER PRODUCTS
AVAILABLE FROM STOCK
DELIVERY SITE
CASE PRESENTATION
ABOUT US
Our factory
Henan Shunzhi Machinery Co.,Ltd. is a modern enterprise specialized in manufacturing mining-equipment which is integrated with research, production, and marketing of the mining equipments. We provide complete sets of mine selection machines, crusher equipment, sand making equipment, and dryer equipment, etc.
WELCOME TO VISIT OUR FACTORY
-- Our customers from over 30 countries and regions.
-- High efficiency,high quality,low cost. We can customize capacity according to customer requirements.
-- We provide engineer to help you with installation, training, our engineers are also available to install overseas if you need.
-- High efficiency,high quality,low cost. We can customize capacity according to customer requirements.
-- We provide engineer to help you with installation, training, our engineers are also available to install overseas if you need.
BUYING PROCESS
AFTER-SALES SERVIECE
Q1. Are you factory or trade company?
A1. We are manufacturer, we also supply trade service.
Q2. What about your price?
A2. We always supply the products with low price, because we believe this is the way to build long-term business and earn good reputation.Our price is 3%-5% lower than the average market price.
Q3. What payment terms do you accept?
A3. Welcome clients to place orders by Alibaba Trade Assurance! Other payment ways such as T/T, L/C, D/P, etc can be negotiated.
Q4. How about your delivery time?
A4: Generally, it will take 15-20 working days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q5: what will you do if the machine is broken down?
A5: The Products warranty is one year. We will provide the technical advice and find the solution immediately for you when the machine is in trouble. For those wear parts, we guarantee the high quality parts for long-term supply.
Q6: How do you make our business long-term and good relationship?
A6: 1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
A1. We are manufacturer, we also supply trade service.
Q2. What about your price?
A2. We always supply the products with low price, because we believe this is the way to build long-term business and earn good reputation.Our price is 3%-5% lower than the average market price.
Q3. What payment terms do you accept?
A3. Welcome clients to place orders by Alibaba Trade Assurance! Other payment ways such as T/T, L/C, D/P, etc can be negotiated.
Q4. How about your delivery time?
A4: Generally, it will take 15-20 working days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q5: what will you do if the machine is broken down?
A5: The Products warranty is one year. We will provide the technical advice and find the solution immediately for you when the machine is in trouble. For those wear parts, we guarantee the high quality parts for long-term supply.
Q6: How do you make our business long-term and good relationship?
A6: 1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
