64 Port 100GE QSFP28 100G Ethernet Switch Switch CE8850 64CQ EI CE8850 EI F B0B
- Category: >>>
- Supplier: Beijing Fengyuan Tengda Technology Co. Ltd.
Share on (1601274497598):
Product Overview
Description
Product Description
CloudEngine 8800 Series Data Center Switches
High performance, high port density, and SDN-ready.
CloudEngine 8800 Series Data Center Switches
A series of high port density switches, CloudEngine 8800 brings a combination of both high performance and low latency to cloud-oriented data center networks and high-end campus networks alike. Additionally, the series supports an extensive range of data center features, Software-Defined Networking (SDN) capabilities, and high performance stacking technologies.
With 10 GE, 25 GE, 40 GE, 100 GE, 200 GE, and 400 GE ports, as well as flexible plug-in cards, CloudEngine 8800 is well suited for both the core and aggregation layers. The series is also compatible with CloudEngine 16800, 12800, 6800, and 5800 series switches, helping enterprises build networks that are scalable, simplified, open — and secure.
Scalability
Flexible, high density access, with aggregation capabilities and up to 32 x 100 GE, 64 x 40 GE, 128 x 25 GE, or 128 x 10 GE ports in a 2U chassis.
Virtualization
Virtual Extensible Local Area Network (VXLAN) turns CloudEngine 8800 into a high-performance hardware gateway on a virtualized overlay network, supporting up to 16 million tenants.
Intelligence
Significantly simplify operations with intelligent Operations and Maintenance (O&M), proactive reporting of Google Remote Procedure Call (gRPC) high-speed data, proactive detection of network-wide paths, and real-time monitoring of network health status.
High performance, high port density, and SDN-ready.
CloudEngine 8800 Series Data Center Switches
A series of high port density switches, CloudEngine 8800 brings a combination of both high performance and low latency to cloud-oriented data center networks and high-end campus networks alike. Additionally, the series supports an extensive range of data center features, Software-Defined Networking (SDN) capabilities, and high performance stacking technologies.
With 10 GE, 25 GE, 40 GE, 100 GE, 200 GE, and 400 GE ports, as well as flexible plug-in cards, CloudEngine 8800 is well suited for both the core and aggregation layers. The series is also compatible with CloudEngine 16800, 12800, 6800, and 5800 series switches, helping enterprises build networks that are scalable, simplified, open — and secure.
Scalability
Flexible, high density access, with aggregation capabilities and up to 32 x 100 GE, 64 x 40 GE, 128 x 25 GE, or 128 x 10 GE ports in a 2U chassis.
Virtualization
Virtual Extensible Local Area Network (VXLAN) turns CloudEngine 8800 into a high-performance hardware gateway on a virtualized overlay network, supporting up to 16 million tenants.
Intelligence
Significantly simplify operations with intelligent Operations and Maintenance (O&M), proactive reporting of Google Remote Procedure Call (gRPC) high-speed data, proactive detection of network-wide paths, and real-time monitoring of network health status.
Parameters | CloudEngine 8850-64CQ-EI | CloudEngine 8850-HAM | CloudEngine 8851-32CQ8DQ-P | CloudEngine 8855-32CQ4BQ |
Ports | 64 x 100 GE QSFP28 | Downlink Ports 32 x 40/100 GE QSFP28 or 32 x 200 GE QSFP56 Uplink Ports 8 x 400 GE QSFP-DD | Downlink Ports : 32 x 40/100 GE QSFP28 or 32 x 200 GE QSFP56 Uplink Ports :8 x 400 GE QSFP-DD | Downlink Ports : 32 x 40/100GE QSFP28 Uplink Ports :4 x 200GE QSFP56 |
Switching Capacity | 12.8 Tbit/s | 19.2 Tbit/s | 19.2 Tbit/s | 8 Tbit/s |
Forwarding Performance | 4482 mpps | 4350 mpps | 4350 mpps | 1200 mpps |
Buffer | 42 MB | 64 MB | 64 MB | 32 MB |
Reliability | LACP Hardware-based BFD | LACP Hardware-based BFD | LACP Hardware-based BFD | LACP BFD for BGP, IS-IS, OSPF, static route, and VXLAN Hardware-based BFD DPFR MoFRR |
O&M | Telemetry Netstream sFlow Enhanced ERSPAN | Telemetry Netstream ERSPAN+ AnyFlow Intelligent Traffic Analysis Packet Event | Telemetry Netstream ERSPAN+ AnyFlow Intelligent Traffic Analysis Packet Event | 1588v2 Telemetry Netstream ERSPAN+ IFIT Packet Event |
Data Center Features | VXLAN routing and bridging BGP EVPN M-LAG DCBX PFC ETS | 32k multicast entries, MoFRR VXLAN routing and bridging BGP EVPN M-LAG 3.0 | VXLAN routing and bridging BGP EVPN M-LAG | 1588v2 MACsec VXLAN routing and bridging BGP-EVPN M-LAG PFC、AI ECN |
Maximum Power Consumption | 965 W | 32 x 200 GE + 8 x 400 GE: 1152 W 32 x 100 GE + 8 x 400 GE: 973 W | 32 x 200 GE + 8 x 400 GE: 1152 W 32 x 100 GE + 8 x 400 GE: 973 W | 541W |
Power Supply | AC: 1200 W AC + 240 V DC HVDC: 1200 W DC: 1200 W | AC: 1200 W | AC: 1200 W | 1200W AC&240V DC 1200 W DC |
Operating Voltage | AC: 90–290 V HVDC: 240 V (188–290 V) 380 V (188–400 V) DC: –38.4 V to –72 V | AC: 90–290 V | AC: 90–290 V | AC：90V to 290V；HVDC: 190V~290V DC: -48V：-38.4V to -72V; +48V DC：+38.4V to+72V |
Parameters | CloudEngine 8865-4C | CloudEngine 8875-24BQ8DQ |
Ports | Supports four half-width flexible cards and flexible combination of five types of cards • 4 x 400GE + 8 x 25GE • 24 x 10GE (electrical) + 2 x 100GE • 24 x 25GE + 2 x 100GE • 16 x 100GE • 10 x 100GE | Downlink Ports : 24 x 200GE QSFP56 Uplink Ports : 8 x 400GE QSFP-DD |
Switching Capacity | 16Tbps | 16Tbps |
Forwarding Performance | 2400Mpps | 2400Mpps |
Buffer | 64MB | 64MB |
Reliability | LACP BFD for BGP, IS-IS, OSPF, static route, and VXLAN Hardware-based BFD DPFR MoFRR | LACP BFD for BGP, IS-IS, OSPF, static route, and VXLAN Hardware-based BFD DPFR MoFRR |
O&M | Telemetry Netstream ERSPAN+ IFIT Packet Event | Telemetry Netstream ERSPAN+ IFIT Packet Event |
Data Center Features | 1588v2 MACsec VXLAN routing and bridging BGP-EVPN M-LAG PFC、AI ECN | 1588v2 MACsec VXLAN routing and bridging BGP-EVPN M-LAG PFC AI ECN |
Power Supply | 2000W AC&240V DC 1800W AC&240V DC 2200W DC 2000W HVDC | 1200W AC&240V DC 1200 W DC |
Power Supply | AC: 1200 W AC + 240 V DC HVDC: 1200 W DC: 1200 W | AC: 1200 W |
Operating Voltage | AC: 90–290 V HVDC: 240 V (188–290 V) 380 V (188–400 V) DC: –38.4 V to –72 V | AC: 90–290 V |
