WR24100 | ||||||
Energy | 24V 100Ah | Weight | 22kg | |||
Charging Temperate Range | 32° ~ 131°F (140°F Max.) | Discharging Temperate Range | -4° ~ 140°F (-20℃- 60℃) | |||
Charge Method | CC/CV | Discharge Current | 100Amps Continuous | |||
Absorb Voltage(CC) | 28 to 28.8 Volts | Discharge Current 3 seconds | <300Amps | |||
Maximum Current | 100Amps @ 77°F (25℃) | Discharge Cut-off Voltage | 20 Volts; Any cell (2.5 Volts) | |||
Recommended Current | 50Amps | Recommended Low Voltage Disconnect | 24 Volts | |||
Recommended CV Time | 15 minutes | Short Circuit Protection | 500A for 250µS | |||
All batteries include an active BMS (Battery Management System) protection circuit that handles cell balancing, low voltage cutoff, high voltage cutoff, short circuit protection and temperature protection for increased performance and longer life | ||||||
