Imx219 Mipi Auto Focus Af CMOS 8MP Camera Module
- Category: >>>
- Supplier: Shenzhen Hstd Improt&export Co. Ltd.
Share on (1601274968674):
Product Overview
Description
Product Description
HD 8MP Image Quality: Equipped with an advanced CMOS sensor delivering 8 Megapixels of stunning clarity, capturing intricate details for professional photography and surveillance needs.
Auto Focus Technology: Boasts an integrated Auto Focus (AF) system that swiftly and precisely adjusts focus, ensuring sharp and vivid photos and videos at any distance.
Efficient MIPI Interface: Features a MIPI interface for high-speed data transfer, minimizing latency and enhancing overall system responsiveness, ideal for real-time image processing applications.
Compact & Versatile Design: The compact and lightweight module design easily integrates into various devices, from smartphones to drones and security cameras, without added bulk.
Broad Compatibility: Supports a wide range of operating systems and development environments, ensuring strong compatibility and facilitating rapid product upgrades and customization for developers.
Detailed Photos
Product Parameters
| Model No | HSTD-4K-AF-V1 | ||
| Image Sensor | IMX219 | ||
| Image Sensor Size | 1/4”CMOS | ||
| Effective Pixels | 3296*2480 | ||
| Pixel size | 1.12umX1.12um | ||
| Optical distortion | ≤0.5% | ||
| Image sensor Data output | Raw Data 10bits | ||
| Video output | MPJG / YUY2 | ||
| SNR max | TBD | ||
| Dynamic range | TBD | ||
| Min. Illumination | ≥0.01LUX at F1.2 | NO LED | |
| Digital interface | USB BUS POWER 5P-1.0mm | ||
| Transfer rates | 480MB/S | ||
| Power requirements | 5V±5% | ||
| Storage temperature | -20℃to70℃ | ||
| operating temperature | -10℃to60℃ | ||
| Power Consumption | NO LED | Max 1.5W | |
| IR-LED | |||
| LED IR-850( | NO | LED | |
| OS | Windows XP /vista/seven/8.1/10/Mac /Android/linux2.6.2(include UVC ) | ||
| Lens view | M6.5 | LENS | |
| Lens Construction | 5P+IR | ||
| F/NO | 2.2 | ||
| EFL | 3.5mm | ||
| FOV | D:80°±3° | ||
| Micro shooting distance | AF 10cm-infinity | ||
| MIC | support MIC | ||
Certifications
Packaging & Shipping
Installation Instructions
FAQ
Q: Who we are?
A: We are a Global leading high-tech enterprise engaged in R&D development and production of camera module.We customize all kinds of USB /MIPI /DVP /IPC/AHD/HDMI camera module from 1 MP to 50 MP
Q: Could you support OEM&ODM?
A: We are able to offer you the best solutions on market by providing you OEM/ODM service.
Q. How long is the delivery time?
A: Normally small quantity orders will be dispatched within 2-5 working days after receiving payment. For bulk order, we will ship out within 10-15 days..
Q. How do we make a business long term and good relationship with you?
A. We will protect our partner's profit by providing them with good quality products and competitive prices. We treat every customer as a friend and do business with everyone sincerely. no matter where they come from.
Q: How can you guarantee quality?
A: For all systems before shipment, will undergo a series of tests, including vibration testing, test for functional interface & RF indicators & sensitivity & meter settings, high and low temperature testing, trial aging testing, test the interface and all wiring, field testing outsides etc.
