HaiLin 2 Pipe Digital FCU Thermostat With Touch Button For 2 or 3 Wire Control Supported External Sensor 220VAC
- Category: >>>
- Supplier: Beijing HaiLin Control Technology Inc.
Share on (1601275527487):
Product Overview
Description
VR
Product Name | HL2036 Series Touch Button Thermostat | ||||||
Model | HL2036DA2-TL0 | ||||||
Power Supply | AC85～250V, 50/60Hz | ||||||
Display Temp.Resolution | 0.5℃ | ||||||
Operating Temperature Range | 0~55℃ | ||||||
Operating Humidity Range | 5-95%RH (No Condensation) | ||||||
Power Consumption | ＜2 W | ||||||
Terminations | One 2.5mm² Or Two 1.5mm² Wires | ||||||
Max Load Current | ＜ 2A (Resistive),＜ 1A (Inductive) | ||||||
Shell Material | PC＋ABS Anti-flaming | ||||||
Protection Class | IP30 | ||||||
External Sensor | NTC10k | ||||||
