high temperature 1430 zirconium ceramic fiber board Refractory Heat Insulation Aluminium silicate Ceramic Fiber Board
- Category: >>>
- Supplier: Ento High Temperature Materials (Jiangsu) Co. Ltd.
Share on (1601275528754):
Product Overview
Description
EPOWOOL® Ceramic Fiber Board
EPOWOOL® Ceramic fiber board is a high temperature rigid product manufactured by a wet forming process using fiber bulk and binders.It offers low thermal conductivity and high temperature stability in application where vibration,mechanical stress and strong erosive forces are present.The excellent rigidity and modulus of rupture inherent to these boards makes them strong and self-supporting,yet relatively lightweight and easy to cut or machine.
EPOWOOL® Ceramic fiber board can be used in a wide range of applications,such as thermal insulation,particularly in areas of fire protection and in domestic applications which have high requirement of environment friendly.
EPOWOOL® Ceramic fiber board can be used in a wide range of applications,such as thermal insulation,particularly in areas of fire protection and in domestic applications which have high requirement of environment friendly.
1000Board | 1260Board | 1400Board | 1430Board | 1600Board | 1800Board | |||||||
Working Temperature | ℃ | 800 | 1000 | 1200 | 1250 | 1450 | 1650 | |||||
Density | kg/m³ | 280 | 280 | 280 | 280 | 400 | 600 | |||||
Rupture strength | Mpa | ≥0.31 | ||||||||||
Heat Linear Shrinkage | % | ≤3(at 1000°C*24h) | 3(at 1260°C*24h) | ≤3(at 1400°C*24h) | ≤3(at 1430°C*24h) | ≤3(at 1600°C*24h) | 3(at 1800°C*24h) | |||||
(GB/T17911.8) | W/mK | 0.13(at average 600°C) 0.17(at average 800°℃) 0.25(at average 1000°C) | ||||||||||
Chemistry | Al2O3 | 34-37 | 38-41 | 45-48 | 32-35 | 70-73 | 78-81 | |||||
Al2O3 +SiO2 | ≥90 | =93 | 94 | ≥94 (Al2O3+SiO2 +ZrO2) | ≥99 | 99.5 | ||||||
ZrO2 | 10-14 | |||||||||||
Organic Ratio | % | ≤7 | ||||||||||
Dimension | mm | 900*600*25/50 1000*600*25/50 | ||||||||||
Packaging | Carton or Pallet | Wooden Box | ||||||||||
* Product density can be customized according to customer requirements in the range of 220-600kg/m3.
* Product thickness can be customized according to customer requirements in the range of 6-120mm
* The data shown are test results obtained under standard procedures and are subject to change
* Different atmosphere and application location, the performance parameters will vary, the specific selection of materials can consult the engineering department.
* Product thickness can be customized according to customer requirements in the range of 6-120mm
* The data shown are test results obtained under standard procedures and are subject to change
* Different atmosphere and application location, the performance parameters will vary, the specific selection of materials can consult the engineering department.
Typical Applications
• Rigid high temperature gaskets and seals
• Fire protection systems
• Domestic boiler heat exchanger linings
• Heat shields for personnel protection
• Trough/distribution linings for conveying aluminium
• Refractory backup for brick and castable
Ento High Temperature Materials (Jiangsu) Co., Ltd.
Our main products include: ceramic fiber board, ceramic fiber shaped parts, ceramic fiber paper, ceramic fiber cotton, ceramic fiber blanket, ceramic fiber module, high temperature binder and coating, nano insulation materials and other refractory insulation products; At the same time, it provides a perfect energy-saving application scheme. Product application temperature covers 800 degrees Celsius to 1800 degrees Celsius.
After years of accumulation, the enterprise has established a stable production management system, reliable quality system and perfect sales channels. Ceramic fiber series products because of its low heat capacity, low thermal conductivity, high refractoriness and other advantages, many users as the preferred energy-saving materials, widely used in petroleum, chemical, electric power, steel, cement, glass, ceramics and other industries.
Products are sold all over the country and exported to the United States, Japan, Vietnam, Turkey and many other countries and regions. We have made efforts for many enterprises in energy saving, light structure of furnace body and improvement of operating environment.
After years of accumulation, the enterprise has established a stable production management system, reliable quality system and perfect sales channels. Ceramic fiber series products because of its low heat capacity, low thermal conductivity, high refractoriness and other advantages, many users as the preferred energy-saving materials, widely used in petroleum, chemical, electric power, steel, cement, glass, ceramics and other industries.
Products are sold all over the country and exported to the United States, Japan, Vietnam, Turkey and many other countries and regions. We have made efforts for many enterprises in energy saving, light structure of furnace body and improvement of operating environment.
1.You are a manufacture or a trading company ?
We are a manufacturer founded in 2002, located in jiangsu China. We not only provide the high quality products with the best price, but also can offer the best pre-sale service and after-service.
2.What kind of product can you offer ?
Our company can offer all kind of refractory insulation materials. For example: Ceramic Fiber Products, Soluble Fiber board, Hydrophobic Fiber board, Microporous Board, monolithic Module, Silicate Products, High-Temperature Binder Etc.
3.Can you provide free samples ?
Free samples are available !
4.What is your MOQ?
We don't have particular MOQ, we can accept any order for any different projects.Price depends on quantity.
5.Can we have a visit to your factory ?
Yes! Of course,welcome to visit our factory at anytime on site or online !
