  • Hot Sale Good Quality 20MP Pixel 25mm C Mount Lens for Industrial Fa Optical Lens
Hot Sale Good Quality 20MP Pixel 25mm C Mount Lens for Industrial Fa Optical Lens
Hot Sale Good Quality 20MP Pixel 25mm C-Mount Lens for Industrial Fa Optical Lens

Hot Sale Good Quality 20MP Pixel 25mm C Mount Lens for Industrial Fa Optical Lens

Share on (1601275699220):


Price:$134.50 - $140.50

Quantity:


Product Overview

Description



Product Features


Highstandard design and stable quality：Using high standard optical performance technology to achieve high product quality
High resolution：High-resolution optical design, compatible with mainstream 20MP industrial cameras, suitable for 20-megapixel cameras with 1.1" chip. Ensuring the clarity of the image
High uniformity：By controlling the weakening of the edge light, using a wide-angle lens, it is also possible to achieve an
overall, bright and fresh image
Low distortion：1.1-inch chip distortion rate is less than 0.1%


Products Description








Application scenarios




Specifications




Product Specifications
Model
ZX-SF2528T
lmag size
1.1”
1“
2/3”

Angle FOV
H
30.4°
27.6°
19.2°
V
23°
20.9°
14.5°
D
37.6°
34.2°
23.9°
Distortion（TV）
<0.1%
<0.1%
<0.03%
F/ON
F=1：2.8-22
Focus Distance（min）
0.1m
Flange Back
17.526mm in air
Back Fouch
29.6mm（min）
Fiter Screw Size
M35.5*PD.5
Focal Length
f=25mm
Mount
C-Mount
Temperature Range
-10~+50°C


Visual field date
Working Distance
Optical Magnification
1.1“ Field of View（mm）
mm
H
V
5000
0.005×
2820
2120
2000
0.013×
1084.6
815.4
1000
0.025×
564
424
900
0.028×
503.6
378.6
800
0.031×
454.8
341.9
700
0.036×
391.7
294.4
600
0.042×
335.1
252.4
550
0.045×
313.3
235.5
500
0.050×
282
212
450
0.055×
256.4
192.1
400
0.061×
231.1
173.8
350
0.070×
207.4
151.4
300
0.081×
174.1
130.9
250
0.096×
146.9
110.4
200
0.118×
119.4
89.5
150
0.154×
91.6
68.6
100
0.221×
63.8
48


Product packaging
