S5731S S48S4X A(48*GE SFP ports, 4*10GE SFP ports, with AC power supply) network 10 gigabit switch
- Category: >>>
- Supplier: Chongqing Yujia Technology Co. Ltd.
Share on (1601276798588):
Product Overview
Description
Product Description
CloudEngine S5731S-S series switches are standard gigabit access switches developed by Hua wei for the distribution market. They can provide full gigabit port access and fixed gigabit uplink ports.
CloudEngine S5731S-S series switches are the latest generation gigabit access switches introduced by Hua wei. Based on HW unified VRP software platform, CloudEngine S5731S-S series switches have enhanced Layer 3 features, simple operation and maintenance, intelligent iStack stacking, flexible Ethernet networking, mature IPv6 features, etc. Widely used in medical, retail, mining, Internet and other industries.
Intelligent stacking
Minimalist network operation and maintenance
Integrated security capability
CloudEngine S5731S-S series switches are the latest generation gigabit access switches introduced by Hua wei. Based on HW unified VRP software platform, CloudEngine S5731S-S series switches have enhanced Layer 3 features, simple operation and maintenance, intelligent iStack stacking, flexible Ethernet networking, mature IPv6 features, etc. Widely used in medical, retail, mining, Internet and other industries.
Intelligent stacking
Minimalist network operation and maintenance
Integrated security capability
Item | Details |
Description | S5731S-S48S4X Bundle(48*GE SFP ports, 4*10GE SFP+ ports, with AC power supply) |
Part Number | 98011806 |
Model | S5731S-S48S4X-A |
First supported version | V200R021C01 |
Details Images
Specification
Item | Specification |
Dimensions without packaging (H x W x D) [mm(in.)] | Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 420.0 mm (1.72 in. x 17.40 in. x 16.54 in.) |
Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 448.0 mm (1.72 in. x 17.40 in. x 17.64 in.) | |
Dimensions with packaging (H x W x D) [mm(in.)] | 185 mm x 650 mm x 550 mm (7.28 in. x 25.59 in. x 21.65 in.) |
Chassis height [U] | 1 U |
Weight without packaging [kg(lb)] | 5.9 kg (13.01 lb) |
Weight with packaging [kg(lb)] | 8.43 kg (18.58 lb) |
Typical power consumption [W] | 93.69 W |
Typical heat dissipation [BTU/hour] | 319.68 BTU/hour |
Maximum power consumption [W] | 128.89 W (150 W AC or 180 W DC) |
141.96 W (600 W AC) | |
Maximum heat dissipation [BTU/hour] | 439.79 (150 W AC or 180 W DC) |
484.38 (600 W AC) | |
MTBF [year] | 64.97 year |
MTTR [hour] | 2 hour |
Availability | >0.99999 |
Noise at normal temperature (acoustic power) [dB(A)] | 45.47 dB(A) |
Noise at normal temperature (acoustic pressure) [dB(A)] | 31.79 dB(A) |
Number of card slots | 0 |
Number of power slots | 2 |
Number of fans modules | 3 |
Redundant power supply | 1+1 |
Pluggable AC and DC power modules can be used together in the same switch, but power modules that use natural heat dissipation and power modules that use air cooling cannot be used together. | |
Long-term operating temperature [°C(°F)] | -5°C to +45°C (23°F to 113°F) at an altitude of 0-1800 m (0-5906 ft.) |
Short-term operating temperature [°C(°F)] | -5°C to +50°C (23°F to 122°F) at an altitude of 0-1800 m (0-5906 ft.) |
Restriction on the operating temperature variation rate [°C(°F)] | When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). |
The device can work for a short period of time when the operating temperature is beyond the normal range, but the following conditions must be met: | |
The operating temperature can exceed 45°C (113°F) for a maximum of 96 consecutive hours in a year. | |
The total time when the operating temperature exceeds 45°C (113°F) in a year is less than or equal to 360 hours. | |
The number of times the operating temperature exceeds 45°C (113°F) is less than or equal to 15 in one year. | |
If any of the preceding conditions is not met, the device may be damaged or an unknown error may occur. | |
Devices cannot start when the temperature is lower than 0°C (32°F). The maximum transmission distance of an optical module used for short-term operation cannot exceed 10 km. | |
Storage temperature [°C(°F)] | -40°C to +70°C (-40°F to +158°F) |
Long-term operating relative humidity [RH] | 5% to 95%, noncondensing |
Long-term operating altitude [m(ft.)] | 0-5000 m (0-16404 ft.) |
Storage altitude [m(ft.)] | 0-5000 m (0-16404 ft.) |
Power supply mode | Pluggable power supply |
Rated input voltage [V] | AC input: 100 V AC to 240 V AC, 50/60 Hz |
High-voltage DC input: 240 V DC | |
DC input: –48 V DC to –60 V DC | |
Input voltage range [V] | AC input: 90 V AC to 290 V AC; 45 Hz to 65 Hz |
High-voltage DC input: 190 V DC to 290 V DC | |
DC input: -38.4 V DC to -72 V DC | |
Maximum input current [A] | The current specifications depend on the pluggable power modules in use. For details, see the related power module specifications. |
Memory | 2 GB |
Flash memory | The physical space is 1 GB. You can run the display version command to view the actual available space. |
Console port | RJ45 |
Eth Management port | RJ45 |
USB | Not supported |
RTC | Supported |
RPS input | Not supported |
Service port surge protection [kV] | - |
Power supply surge protection [kV] | Configured with AC power modules: ±6 kV in differential mode and ±6 kV in common mode |
Configured with DC power modules: ±2 kV in differential mode and ±4 kV in common mode | |
Types of fans | Built-in |
Heat dissipation mode | Heat dissipation with fan, intelligent fan speed adjustment |
Airflow direction | Air intake from left,front and right, air exhaustion from behind |
PoE | Not supported |
